Product Introduction
In demanding power generation applications, the Woodward 8440-2057 Industrial Automation Module provides robust control for single or multiple gensets. Part of the easYgen-3000 series, this model is an easYgen-3100 with Package 2 (P2) option, designed for cabinet back mounting without an integrated display. It supports mains parallel operations and a range of load management tasks, making it ideal for upgrading legacy genset controllers.
Technical Specifications
| Parameter |
Value |
| Front Panel Dimensions |
282W x 216H x 96D mm |
| Manufacturer |
Woodward |
| Max. Power Consumption per Path |
< 0.15 W |
| Measuring Frequency |
50/60 Hz (40 – 85 Hz) |
| Operating Temperature |
-20 to 70°C |
| Resolution |
11 Bit |
These specifications ensure reliable performance in harsh environments and precise control for both gas and diesel engines.
Industry Applications
The Woodward 8440-2057 excels in single and multi-unit genset systems, connecting up to 32 units. Typical applications include:
- Mains parallel operations for prime power or standby systems
- Load management with 1A CT inputs and external analog I/Os via CANopen
- Engine cylinder temperature protection and three freely configurable PID controllers
Its flexible start/stop logic supports both gas and diesel engines, making it a versatile upgrade for older controllers.
Installation & Setup Guidance
The Woodward 8440-2057 features a metal housing with no display, intended for cabinet back mounting. Setup requires a PC running ToolKit software for configuration. All programming is done via the CANopen interface. When wiring, ensure proper connection of 1A CT inputs and external analog I/Os. The module supports multi-lingual menus and multi-level password protection for security.
Compatibility & Integration
This unit is fully compatible with the easYgen-3000 series ecosystem and integrates seamlessly via CANopen. It works with both gas and diesel engines and supports 12 alarm outputs (10 configurable) for generator load balance, speed/frequency mismatch, and mains phase shift/rotation field monitoring. For system expansion, the module can connect to external analog I/O modules.
Selection Guide & Purchasing Advice
Before purchasing the Woodward 8440-2057, verify that your system requires the Package 2 (P2) variant and that CANopen communication is available. Ensure the cabinet has adequate space for the 282x216x96 mm enclosure. For a reliable source, visit ubest101 to confirm stock and compatibility with your existing genset control setup.
