Product Overview
The Bently Nevada 3500/45-05-00 Position Monitor is a dedicated industrial automation module designed for precise position monitoring in critical rotating machinery. As part of the trusted 3500 series, this module integrates seamlessly into existing monitoring systems, providing reliable data for predictive maintenance and asset protection.
Built for demanding environments, the 3500/45-05-00 uses AC LVDT technology to deliver accurate displacement measurements, ensuring operators can detect issues before they escalate. This module is supplied new and in original factory packing, backed by a 12-month factory warranty.
Key Features
- AC LVDT Position I/O Module with internal terminations
- Factory warranty: 12 months
- New & original in factory packing
- Part of the Bently Nevada 3500 series
Technical Specifications
The following specifications are directly from the manufacturer's ordering data for the 3500/45-05-00:
| Parameter |
Value |
| Model |
3500/45 Position Monitor |
| I/O Module Type |
05 = AC LVDT Position I/O Module with Internal Terminations |
| Agency Approval |
00 = None |
These parameters define the module's configuration, ensuring compatibility with your existing 3500 rack systems.
Applications
The Bently Nevada 3500/45-05-00 is ideal for applications where precise position feedback is critical, such as:
- Steam and gas turbine monitoring
- Compressor and pump protection
- Generators and other rotating equipment
By integrating this module into your condition monitoring system, you gain real-time insight into shaft position, helping to avoid unplanned downtime and extend equipment life.
Installation Guidance
When installing the 3500/45-05-00, follow the manufacturer's guidelines for module insertion into the 3500 rack. Ensure the rack is powered down before handling to prevent damage. The internal terminations simplify wiring; verify all connections are secure and match your system's configuration.
Maintenance & Reliability
The 3500/45-05-00 requires minimal maintenance due to its solid-state design. Periodically inspect the module for dust accumulation and ensure the rack's cooling vents are clear. Regular system checks will help maintain accurate readings and prolong the module's service life.
Compatibility & Integration
This module is designed to operate within the Bently Nevada 3500 monitoring system, which accepts multiple I/O modules for comprehensive machinery protection. The 3500/45-05-00 integrates with the rack's communication modules to relay data to your control system.
Selection Guide
Before ordering, confirm that your system requires the AC LVDT input type and that the agency approval option (00 = None) meets your site's regulations. If you need assistance, PLC Source PRO offers expert support to help you choose the right module for your application.
