Product Introduction
The Woodward 8440-1945 is a high-performance industrial automation module from the EasYgen-3000 series. Also known as the EasYgen-3400-1-P1, this controller is designed for generator management and protection. It offers advanced control capabilities in a compact sheet metal frame without an LCD screen, ideal for remote operation. The Woodward 8440-1945 supports eleven application modes, including GCB/L-GGB and GCB/GGB/L-MCB, making it versatile for various power generation setups.
Technical Specifications
The Woodward 8440-1945 delivers precise performance with the following parameters:
| Parameter |
Value |
| Accuracy Class |
0.5 |
| Front Panel Dimensions |
282W x 216H x 96D mm |
| Manufacturer |
Woodward |
| Primary Setting Range |
50 – 650,000 Vac |
| Setting Range |
1 – 32,000 A |
| Storage Temperature |
-22 to 176 °F |
| Weight |
Approx. 1,850 g (4 lbs) |
These specs ensure the Woodward 8440-1945 can handle demanding generator control tasks with high accuracy.
Industry Applications
The Woodward 8440-1945 excels in applications requiring precise generator paralleling and mains failure management. Common use cases include:
-
Auto Mains Failure (AMF): The controller automatically starts and stops the generator upon mains loss, ensuring uninterrupted power.
-
Mains Parallel & Islanded Operation: It supports both grid-connected and standalone modes, allowing flexible energy management.
-
Master/Slave Configurations: Multiple units can be synchronized for larger power plants using master/slave control.
With the Woodward 8440-1945, operators benefit from reduced downtime and improved system reliability.
Installation & Setup Guidance
The Woodward 8440-1945 is designed for cabinet mounting. Its sheet metal housing lacks an LCD, so operators should configure it remotely via expansion boards and analog I/O. Follow these guidelines for proper setup:
- Mount the module securely in a clean, dry cabinet with adequate ventilation.
- Connect analog I/O and discrete expansion boards as per the wiring diagram for your application mode.
- Verify the primary setting range (50–650,000 Vac) and current range (1–32,000 A) match your generator parameters before energizing.
- Use the P1 series' reduced interface count to simplify connections in space-constrained panels.
Selection Guide & Purchasing Advice
When purchasing the Woodward 8440-1945, confirm compatibility with your existing control system. This module is a direct equivalent to the EasYgen-3400-1-P1. For reliable supply and competitive pricing, choose PLC Source PRO (available at ubest101). Ensure your system can support the analog I/O and expansion board requirements for your chosen application mode.
