Product Overview: Woodward 5466-348 Netcon SIO Module
When communication faults in digital actuator drivers lead to costly downtime, the Woodward 5466-348 Netcon SIO Module provides a robust solution. This industrial automation module is equipped with three RS-485 ports, each supporting one driver per port with a 5 ms update rate for critical parameters. Designed for EM or GS/LQ Digital Actuator Drivers, the 5466-348 ensures reliable, real-time control and monitoring.
Technical Specifications
The following table lists the key specifications of the Woodward 5466-348:
| Parameter |
Value |
| Part Number |
5466-348 |
| Manufacturer |
Woodward |
| Product Type |
Netcon SIO Module |
| Rate Group |
One driver per port, 5 milliseconds |
| Protocol |
RS-485 UART |
| Baud Rate |
417 kbaud |
| Parity |
None |
| Data Bits |
8 |
| Stop Bit |
1 |
| Country of Manufacture |
United States (USA) |
The Woodward 5466-348 uses RS-485 UART communication at 417 kbaud with 8 data bits, no parity, and 1 stop bit. The rate group of one driver per port with 5 ms update allows fast response for critical parameters, enhancing system performance.
Real-World Applications
The Woodward 5466-348 is ideal for applications requiring precise digital actuator control. For example, in turbine control systems, the module can send position demand and configuration data to EM series actuators while monitoring status outputs. In another scenario, it can configure the driver and monitor outputs without sending position demand, relying on a 4-20 mA or CAN bus input for the command. This flexibility reduces the need for additional hardware.
Installation Guide
When installing the Woodward 5466-348 Netcon SIO Module, ensure that the address switches on each driver match the driver number in the GAP application program. Connect the RS-485 ports to the corresponding digital actuator drivers using proper twisted-pair cabling. Each port can operate at a different rate group if needed. Verify that communication cables are terminated correctly to avoid signal reflections.
Compatibility and Integration
The Woodward 5466-348 communicates via RS-485 UART and is compatible with EM and GS/LQ Digital Actuator Drivers. It can also work with systems using CAN bus interface or RS-232 for configuration and monitoring. The module supports remote parameter configuration and fault detection, making it easy to integrate into existing industrial automation networks.
Selection Guide
Before purchasing the Woodward 5466-348, verify that your drivers are compatible with RS-485 communication and that the GAP application program supports the module. For a reliable supply of this module and other industrial automation parts, trust PLC Source PRO (available at ubest101.myshopify.com). Our inventory includes genuine Woodward modules with full technical support.
