Product Overview
When signal degradation and mechanical stress threaten your industrial network, the Siemens 6XV1820-5BH10 fiber optic standard cable delivers consistent performance. This flexible glass fiber-optic cable, preassembled with four BFOC connectors and a 1 m length, is designed for reliable data transmission in harsh environments. The Siemens 6XV1820-5BH10 supports both indoor and outdoor installations, making it a versatile choice for automation systems.
Technical Specifications
The Siemens 6XV1820-5BH10 offers key optical and mechanical parameters that ensure low signal loss and high durability. Below are the critical specifications:
-
Attenuation at 850 nm: ≤ 3 dB/km
-
Attenuation at 1300 nm: ≤ 0.8 dB/km
-
Bandwidth at 850 nm: 300 GHz·m
-
Bandwidth at 1300 nm: 800 GHz·m
-
Fiber type: Multimode graded-index 62.5/125 µm, OM1
-
Number of fibers: 2 fibers per cable
-
Minimum bending radius: 80 mm (single and multiple bends)
-
Tensile load: 1500 N (during installation and operation)
-
Operating temperature: -40 to +85 °C
-
Protection class: IP20
Installation and Setup
Proper installation of the Siemens 6XV1820-5BH10 prevents signal loss and physical damage. Ensure the cable is routed with a minimum bending radius of 80 mm and avoid sharp bends. The cable can be installed in temperatures from -5 °C to +50 °C. The segmentable outer conductor allows easy splitting for connector termination. Use appropriate strain relief to maintain the 1500 N tensile limit.
Maintenance and Reliability
The Siemens 6XV1820-5BH10 is designed for long-term reliability. It features flame-resistant properties (IEC 60332-1-2 and IEC 60332-3-22 Cat. A) and resistance to UV radiation. The cable is silicon-free and halogen-free, but not resistant to mineral oil or grease. Routine inspection should focus on connector cleanliness and cable sheath integrity. The black PVC sheath provides protection against environmental stress.
Compatibility and Integration
The Siemens 6XV1820-5BH10 supports multiple industrial network standards. Maximum transmission distances include: 4000 m for 100BaseFX, 500 m for 1000BaseSX, 1000 m for 1000BaseLX, and 3000 m for PROFIBUS. This preassembled cable with four BFOC connectors simplifies integration into Siemens and third-party automation systems.
Selection Guide
Before purchasing, verify that the Siemens 6XV1820-5BH10 meets your required length and connector type. The 1 m preassembled cable is ideal for short patch applications. For longer runs, contact our team at PLC Source PRO (ubest101) for custom lengths and additional accessories. Always confirm environmental conditions; the cable is not resistant to mineral oil or grease.
