Product Introduction
With PROFIBUS DP and AS-Interface V3.0 capabilities, the Siemens 6GK1415-2AA10 Industrial Automation Module serves as a reliable gateway between PROFIBUS DP and AS-Interface networks. Designed for control systems requiring high data throughput and robust connectivity, this module integrates seamlessly into existing Siemens automation environments. The 6GK1415-2AA10 is the ideal upgrade for older AS-i gateways, offering support for up to 62 slaves and faster bus cycle times.
Technical Specifications
| Parameter |
Value |
| Protection class (IP) |
IP20 |
| Type of electrical connection |
Screw-type connection |
| Current consumption at 30 V (max) |
200 mA |
| Power loss |
4.5 W |
| Rated insulation voltage |
500 V |
| Redundancy capability |
Yes (via Y-Link) |
| Galvanic isolation |
Yes |
| AS-Interface specification version |
V3.0 |
| AS-Interface master profile |
M4 |
| Maximum number of inputs/outputs |
496 each |
| Maximum number of AS-i slaves |
62 |
| Bus cycle time (31 slaves) |
5 ms |
| Bus cycle time (62 slaves) |
10 ms |
| Dimensions (width x height x depth) |
90 x 80 x 62 mm |
| Mounting method |
Snap-on on 35 mm DIN rail |
| Ambient temperature (horizontal mount) |
0 to 60 °C |
| Ambient temperature (vertical mount) |
0 to 45 °C |
| Operating relative humidity at 25 °C |
≤95% |
All specifications are directly from the product database for the 6GK1415-2AA10. No data is inferred.
Installation & Setup
Mount the Siemens 6GK1415-2AA10 on a standard 35 mm DIN rail using its snap-on fastening. The module requires a screw-type connection for the AS-Interface cable. Ensure proper ventilation; the ambient temperature must not exceed 60 °C when mounted horizontally or 45 °C vertically. The device accepts power directly from the AS-Interface bus at up to 30 V, drawing a maximum of 200 mA. Use the pushbutton on the device, STEP7, GSD file, or command interface for configuration.
Compatibility & Integration
The 6GK1415-2AA10 integrates with any PROFIBUS DP master and complies with AS-Interface specification V3.0. It supports the M4 master profile and can handle up to 62 AS-i slaves. The module provides galvanic isolation and is suitable for both digital and analog I/O access. It is not compatible with PROFINET, Industrial Ethernet, or wireless interfaces. For redundancy, use the Y-Link option. This gateway is an excellent choice for replacing older AS-Interface links in existing Siemens systems.
Selection Guide & Purchasing Advice
Before purchasing the Siemens 6GK1415-2AA10, verify that your PROFIBUS DP network meets the voltage and communication requirements. Ensure your AS-Interface slaves are V3.0 compatible to leverage full functionality. For a reliable source, visit ubest101 — a trusted supplier of industrial automation spares. This module provides a cost-effective upgrade path from older AS-i networks, reducing bus cycle times from 10 ms to as low as 5 ms for 31 slaves.
FAQ
Can the 6GK1415-2AA10 be used with PROFINET?
No, the Siemens 6GK1415-2AA10 does not support PROFINET. It is designed for PROFIBUS DP and AS-Interface communication only.
What is the maximum number of slaves supported?
The gateway supports up to 62 AS-i slaves per AS-Interface network.
Is this module suitable for safety applications?
No, the 6GK1415-2AA10 is not intended for safety-related functions. It does not support ASIsafe or PROFIsafe protocols.
What are the mounting requirements?
Mount the module on a 35 mm DIN rail using the snap-on mechanism. The device must be installed in a location with ambient temperature within the specified ranges and relative humidity below 95% at 25 °C.
Does the module support redundancy?
Yes, the 6GK1415-2AA10 has redundancy capability when used in conjunction with a Y-Link.
