Schneider 140NRP31200: Ethernet Fiber Converter Specs
Schneider 140NRP31200 Ethernet Fiber Converter Overview
The Schneider 140NRP31200 is an Ethernet fiber converter designed for industrial automation networks. It enables reliable data transmission over long distances using fiber optic cabling. This device converts electrical Ethernet signals to optical signals, ensuring robust communication in harsh environments.
Key Technical Specifications
The 140NRP31200 supports standard Ethernet protocols and operates with multimode fiber. It provides a transmission distance of up to 2 kilometers, making it suitable for connecting remote devices or control cabinets. The converter uses a standard SC connector for fiber connection and includes an RJ45 port for electrical Ethernet input. It operates on a 24 VDC power supply, common in industrial settings.
How the 140NRP31200 Works
The device receives electrical Ethernet signals from a controller or switch via the RJ45 port. It then converts these signals into light pulses for transmission over fiber optic cable. At the receiving end, another converter reverses the process. This method eliminates electromagnetic interference and allows for longer cable runs without signal degradation.
Best Practices for Deployment
Install the 140NRP31200 in a clean, dry environment within an IP20-rated enclosure. Use multimode fiber with a 62.5/125 µm core for optimal performance. Ensure the power supply provides stable 24 VDC within the specified tolerance. For maximum reliability, avoid sharp bends in the fiber cable and keep connectors clean.
Benefits for Engineers
Automation engineers appreciate the 140NRP31200 for its plug-and-play operation. It requires no configuration, reducing setup time. The fiber optic connection provides galvanic isolation, protecting equipment from ground loops and voltage surges. This makes it ideal for use in factories, substations, or transportation systems where reliability is critical.
In summary, the Schneider 140NRP31200 Ethernet fiber converter offers a simple, effective solution for extending network reach in industrial environments. Its robust design and easy integration make it a valuable component for modern automation systems.
