Product Overview
Upgrade your automation network with the Siemens 6FX8002-2DC10-1BG0 DRIVE-CLiQ signal cable. This pre-assembled cable is designed for reliable communication between SINAMICS S120 drives and control systems. Featuring a 24V plug with RJ45 connector rated IP20 on the module side and IP67 on the motor side, it withstands harsh industrial environments. The cable supports lengths up to 75 meters with a diameter of 7.1 mm, making it suitable for medium-distance connections in motor feedback and control loops.
Technical Specifications
| Parameter |
Value |
| Product Type |
Pre-assembled DRIVE-CLiQ signal cable |
| Article Numbers |
6FX80022DC101BG0 / 6FX80022DC101BG0 |
| Connector Type (Module Side) |
RJ45 with 24V plug, IP20 |
| Connector Type (Motor Side) |
IP67 |
| Maximum Length |
75 m |
| Outer Diameter (Dmax) |
7.1 mm |
| Net Weight |
2.463 lb (approx. 1.117 kg) |
| Packaging Quantity |
1 piece |
| Country of Origin |
Slovakia |
| UPC |
662643414219 |
| Product Lifecycle |
PM300:Active |
| Lead Time (ex-works) |
15 days |
| Commodity Code |
85444290 |
Industry Applications
The Siemens 6FX8002-2DC10-1BG0 is specifically designed for SINAMICS S120 Motor Modules and SINUMERIK 840D sl CNC controllers. Typical applications include conveyor systems, machine tool spindles, and packaging machinery where precise motor control and feedback are critical. The MOTION-CONNECT 800PLUS cable ensures high signal integrity even in electrically noisy environments.
Installation & Setup Guidance
Before installation, verify that the cable length (available in 0, 10, 6, and 0 meter versions per the specification) suits your application routing. Ensure the RJ45 connector on the module side is securely plugged into the DRIVE-CLiQ interface. The IP67 motor-side connector requires proper sealing to maintain protection. Avoid sharp bends that exceed the minimum bending radius of the cable to prevent internal damage. For best performance, keep the cable away from high-voltage power lines.
Compatibility & Integration
This cable is compatible with SINAMICS S120 drive systems (both Motor Modules and Control Units) and SINUMERIK 840D sl controllers. It supports DRIVE-CLiQ digital communication protocol. The 24V plug delivers power for the motor-side encoder electronics, enabling single-cable solutions. Replace older MOTION-CONNECT 700 cables with this 800PLUS version for improved durability and signal quality.
Selection Guide & Purchasing Advice
When selecting the Siemens 6FX8002-2DC10-1BG0, confirm your system's required cable length and connector orientation. This cable is a direct replacement for similar DRIVE-CLiQ cables in existing Siemens installations. For reliable sourcing, consider PLC Source PRO (available via ubest101.myshopify.com) which stocks genuine Siemens parts with traceable documentation. Always order the exact model number to ensure fit and function.
