Product Introduction
When signal degradation disrupts motor feedback in high-speed automation, the Siemens 6FX8002-2DC10-1BF0 provides a reliable solution. This pre-assembled motor encoder cable from the 6FX series delivers consistent Drive-Cliq connectivity for demanding industrial environments. The 6FX8002-2DC10-1BF0 features a 15‑meter length, green polyurethane (PUR) jacket, and straight RJ45 connectors on both ends, ensuring robust data transmission between Siemens drives and motors.
Technical Specifications Breakdown
The key parameters of the Siemens 6FX8002-2DC10-1BF0 directly address common signal‑integrity challenges:
-
Cable Length: 15.0 m – Sufficient for medium‑span drive‑to‑motor connections without signal loss.
-
Connector Type (Both Ends): RJ45 – Standardized interface for Drive‑Cliq communication, supporting 24 V supply.
-
Jacket Material: Polyurethane (PUR) – Resistant to oils, wear, and mechanical stress in factory floors.
-
Jacket Color: Green – Eases visual identification in dense cable trays.
-
IP Ratings: IP20 on module side, IP67 on motor side – Protects against dust and water ingress at the motor connection.
Industry Applications
The Siemens 6FX8002-2DC10-1BF0 excels in servo‑drive feedback loops for CNC machine tools and industrial robots. In a typical installation, this cable replaces an older, non‑Drive‑Cliq assembly to upgrade communication speed and diagnostic capabilities. The 15‑meter length fits automotive production lines where drive cabinets sit separated from motors.
Installation & Setup Guidance
When replacing an existing motor encoder cable with the Siemens 6FX8002-2DC10-1BF0, follow standard wiring practices. Route the cable away from high‑voltage power lines to avoid electromagnetic interference. Use cable ties or clamps to secure the PUR jacket and prevent strain on the RJ45 connectors. Ensure the motor‑side connector remains within the IP67 rating by verifying that the seal is intact.
Compatibility & Integration
The 6FX8002-2DC10-1BF0 is designed for Siemens SINAMICS drives and motors that support the Drive‑Cliq interface. It integrates directly with G120, S120, and V90 series controllers. No additional adapters are needed – simply plug the RJ45 connectors into the respective ports on the module and motor.
Selection Guide & Purchasing Advice
Before purchasing the Siemens 6FX8002-2DC10-1BF0, confirm your drive model supports Drive‑Cliq and that the 15‑meter length suits your layout. This cable is a direct replacement for original Siemens part number 6FX80022DC101BF0. For reliable supply, order from PLC Source PRO (store: ubest101.myshopify.com), where you can find genuine Siemens automation spares.
