Product Overview
When signal interference leads to drive faults, the Siemens 6FX8002-2DC10-1BB0 signal cable provides a robust and reliable connection for demanding industrial automation environments. This pre-assembled cable features DRIVE-CLiQ interface with a 24 V plug, ensuring secure communication between modules and motors. Designed for use with SINAMICS S120 and SINUMERIK 840D sl systems, the 6FX8002-2DC10-1BB0 handles high-speed data transfer while minimizing signal degradation over long runs.
The cable is built with a MOTION-CONNECT 800PLUS design, rated for lengths up to 75 meters, making it suitable for large-scale installations. Its dual IP rating—IP20 on the module side and IP67 on the motor side—protects against dust and water ingress in harsh factory conditions. With a diameter maximum of 7.1 mm, the 6FX8002-2DC10-1BB0 remains flexible enough for tight cable routing while maintaining durability.
Real-World Applications
The Siemens 6FX8002-2DC10-1BB0 is essential in applications requiring precise motion control over long distances. In automated assembly lines, this cable links servo drives to motor modules, ensuring real-time position feedback without latency. For CNC machining centers using SINUMERIK 840D sl, the cable supports high-speed spindle control and multi-axis coordination, reducing downtime from communication errors.
In packaging and material handling systems, the robust IP67 motor-side connector withstands washdown environments, while the IP20 module-side interface fits seamlessly into control cabinets. The pre-assembled nature of the 6FX8002-2DC10-1BB0 simplifies installation, cutting labor costs and eliminating field wiring errors that cause signal noise.
Installation & Setup
Installing the Siemens 6FX8002-2DC10-1BB0 requires attention to cable routing and bending radius. Although the cable is flexible (Dmax 7.1 mm), avoid sharp bends near connectors to prevent internal strain. Ensure the 24 V plug is securely latched on the module side, and tighten the RJ45 connector to the specified torque. For lengths approaching 75 meters, use cable ties to secure the cable along machine frames, preventing snagging.
On the motor side, the IP67 connector must be fully seated and the locking ring tightened to maintain environmental sealing. Always verify that the cable is not routed near high-voltage power lines to avoid electromagnetic interference. Pre-commissioning continuity testing is recommended to confirm that the DRIVE-CLiQ interface is properly terminated.
Compatibility & Integration
The Siemens 6FX8002-2DC10-1BB0 is specifically engineered for SINAMICS S120 Motor Modules and SINUMERIK 840D sl control systems. It uses the DRIVE-CLiQ protocol, which is a Siemens proprietary interface for high-speed servo and inverter communication. The cable is compatible with any Siemens drive component that accepts a DRIVE-CLiQ connection with a 24 V power supply line.
This model cannot be used with other fieldbus systems like PROFIBUS or EtherNet/IP without a converter. Because it is pre-assembled, it is not field-terminable; always select the exact length needed. For integration into existing systems, confirm that your drive firmware supports the cable length (up to 75 m) to maintain signal integrity.
Selection Guide & Purchasing Advice
Before purchasing the Siemens 6FX8002-2DC10-1BB0, measure the exact distance from the drive module to the motor, adding a small service loop. The cable is available in fixed lengths (the specific variant is 1BB0, likely 10 meters as per part numbering convention). Verify that your motor-side connector matches the IP67 pinout. For longer runs, consider the total system length limitations of DRIVE-CLiQ (maximum 100 m per segment).
For reliable sourcing and fast delivery, contact ubest101 (PLC Source PRO) for genuine Siemens inventory. Our team can confirm lead times and stock availability for the 6FX8002-2DC10-1BB0.
