Product Introduction
With a 10-meter length and a robust 4x1.5 mm² conductor configuration, the Siemens 6FX3002-5CL02-1BA0 provides a reliable power connection for industrial automation systems. This power cable is pre-assembled for motor S-1FL6 HI 400 V with V70/V90 frame size AA, featuring MOTION-CONNECT 300 design (No UL) and a straight connector for fixed cable outlet direction. The Siemens 6FX3002-5CL02-1BA0 is engineered to deliver consistent power transmission in demanding factory environments.
Technical Specifications Breakdown
The Siemens 6FX3002-5CL02-1BA0 boasts several key parameters that ensure performance and longevity. Below is a detailed breakdown of its electrical and mechanical specifications:
| Parameter |
Value |
| Number of cores x cross-section |
4 x 1.5 mm² |
| Test voltage, rms (power conductors) |
4000 V |
| Rated voltage U0/U per EN 50395 (power conductors) |
600 V / 1000 V |
| Smallest bending radius (fixed installation) |
6 x diameter |
| Smallest bending radius (flexible installation) |
155 mm |
| Maximum number of bends |
1,000,000 |
| Tensile stress, max. (fixed installation) |
50 N/mm² |
| Tensile stress, max. (flexible installation) |
20 N/mm² |
| Torsional stress absolute |
30°/m |
| Connection type |
Straight connector (fixed cable outlet) |
| Length |
10.0 m |
These specifications highlight the cable's ability to withstand high voltage stress, mechanical strain, and repeated flexing, reducing the risk of downtime from cable failure.
Compatibility & Integration
The Siemens 6FX3002-5CL02-1BA0 is specifically designed for use with Siemens S-1FL6 HI 400 V motors and V70/V90 drive systems with frame size AA. It integrates seamlessly into motion control applications using MOTION-CONNECT 300 cabling. When upgrading or replacing power cables in your automation system, verify that your motor and drive match these requirements to ensure proper fit and performance.
Industry Applications & Use Cases
Thanks to its high tensile strength and bend cycle rating, the Siemens 6FX3002-5CL02-1BA0 excels in applications requiring constant cable movement or routing in tight spaces. Typical use cases include:
- CNC machining centers where the cable withstands repeated flexing from axis motion.
- Conveyor systems needing reliable power delivery to servo motors.
- Robotic pick-and-place cells where torsional stress from cable twisting is common.
In each scenario, the cable's 1,000,000 bend cycles and 50 N/mm² fixed tensile stress ensure long service life, reducing replacement costs and unplanned downtime—key drivers for return on investment.
Installation & Setup Guidance
Install the Siemens 6FX3002-5CL02-1BA0 by connecting the straight connector to the motor side, ensuring the connector is fully seated. For fixed installations, maintain a bending radius of at least 6 times the cable diameter; for flexible routing, keep bends to a minimum radius of 155 mm. Use cable ties or clamps to secure the cable and prevent excessive movement. Avoid running the cable near sharp edges or heat sources to preserve insulation integrity.
Selection Guide & Purchasing Advice
Before purchasing the Siemens 6FX3002-5CL02-1BA0, confirm that your motor model (S-1FL6 HI 400 V) and drive (V70/V90 frame AA) are compatible. Also check that your system requires a straight connector with fixed cable outlet and a length of 10.0 meters. For other lengths or connector types, contact a knowledgeable supplier like ubest101 to find the right MOTION-CONNECT 300 cable variant. Proper selection ensures efficient commissioning and long-term reliability.
