Product Overview
When upgrading or replacing power connections in Siemens V90 servo drive systems, the Siemens 6FX3002-5CK32-1AD0 power cable delivers a reliable, preassembled solution. This cable eliminates field termination errors and minimizes downtime during motor replacement. Part of the Motion-Connect 300 series, the Siemens 6FX3002-5CK32-1AD0 is engineered for direct compatibility with S-1FL6 low-inertia motors operating at 200V.
Key Specifications
Based on product data, the Siemens 6FX3002-5CK32-1AD0 includes the following characteristics:
- Preassembled construction with 4x2.5 mm² conductors
- Designed for Siemens S-1FL6 motor series (200V SH50 variant)
- Compatible with V90 drives framesize D
- Motor-side straight connector with Dmax 9.7mm
- Total length: 3 meters
- Non-UL rated (suitable for non-North American installations)
- Packaging dimensions: 500 x 500 x 80 mm
- Net weight: 0.670 kg
Application and Use Cases
The Siemens 6FX3002-5CK32-1AD0 serves as a direct replacement cable for existing S-1FL6 motor installations using V90 drives. Typical applications include packaging machinery, material handling, and assembly line robotics where precise motion control is required. The 3-meter length suits compact machine layouts and allows flexible routing between drive and motor.
Installation Guidance
Mount the Siemens 6FX3002-5CK32-1AD0 by connecting the straight motor-side connector to the S-1FL6 motor. Ensure the connector seats fully and the locking mechanism engages. Route the cable away from sharp edges and secure it using cable clamps to prevent strain on the connector. Verify the drive end connection matches the V90 framesize D terminal layout.
Compatibility and Integration
This cable is specifically designed for the Siemens V90 servo drive family with framesize D and S-1FL6 motors rated at 200V. It is part of the Motion-Connect 300 series, ensuring signal integrity and mechanical fit. The cable does not include UL certification, so verify local code requirements for installations outside North America.
Selection Guide
Before purchasing the Siemens 6FX3002-5CK32-1AD0, confirm your motor model is S-1FL6 with SH50 winding and 200V rating. Check the drive framesize; this cable matches V90 framesize D. If your application requires a longer or shorter length, or a different connector configuration, contact PLC Source PRO for alternatives. For reliable supply of genuine Siemens automation cables, trust PLC Source PRO (ubest101).
