Product Introduction
When high-flex cabling for absolute encoder feedback is required in servo drives, the Siemens 6FX3002-2DB10-1AF0 Industrial Automation Module delivers reliable signal transmission. This pre-assembled signal cable is designed for use with ABS encoders in S-1FL6 HI motors, featuring a MOTION-CONNECT 300 design for dynamic applications. With a 5-meter length and robust construction, it ensures consistent performance in industrial automation environments.
Technical Specifications Breakdown
| Parameter |
Value |
| Cores & Cross-section |
3x2x0.22 + 2x2x0.25 mm² |
| Test Voltage (rms) on Power Conductors |
500 V |
| Rated Voltage U0/U per EN 50395 |
30 V / 30 V |
| Smallest Bending Radius (fixed) |
6 x diameter (155 mm) |
| Number of Bends, max. |
1,000,000 |
| Tensile Stress, max. Fixed Installation |
50 N/mm² |
| Tensile Stress, max. Flexible Installation |
20 N/mm² |
| Torsional Stress Absolute |
30°/m |
| Length |
5.0 m |
These specifications demonstrate that the Siemens 6FX3002-2DB10-1AF0 is engineered for high-flex applications requiring up to one million bend cycles, reducing the risk of cable fatigue and downtime.
Installation & Setup Guidance
Install the Siemens 6FX3002-2DB10-1AF0 signal cable by first ensuring the encoder and drive system are powered off. Connect the angular connector, which rotates in fixed increments—note that connector disassembly may be required when altering the cable outlet direction. Secure the cable with a minimum bending radius of 155 mm for fixed installations. For flexible routing, avoid exceeding the rated tensile stress of 20 N/mm². Ensure the cable is not subjected to torsional stress beyond 30°/m.
Maintenance & Reliability
The Siemens 6FX3002-2DB10-1AF0 requires minimal maintenance. Regularly inspect the cable for cuts, kinks, or signs of wear, especially in high-flex areas. The high bend cycle rating (1,000,000) contributes to long service life, reducing replacement costs and downtime. Use cable carriers that maintain the specified bending radius to maximize reliability. From a cost-benefit perspective, investing in this cable minimizes unexpected failures in critical automation lines.
Selection Guide & Purchasing Advice
When selecting the Siemens 6FX3002-2DB10-1AF0, verify compatibility with your absolute encoder and motor series (S-1FL6 HI). Check the cable length and connector type. For additional support, contact ubest101 to confirm fit with your system. PLC Source PRO provides genuine Siemens parts with fast shipping.
