Product Introduction
The Siemens 6FX2007-1AD03 mini handheld unit is designed specifically for Sinumerik CNC controls. It features a 3.5-meter coiled cable, a 2-channel emergency stop, and a 3-step enabling button with metal connector handwheel and magnetic latching. This unit provides essential operator control and safety in demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Operating Voltage (DC encoder) |
5 V |
| Operating Voltage Tolerance |
+/- 5% |
| Power Consumption (max) |
4.5 W |
| Current Consumption (no load, max) |
100 mA |
| Scanning Frequency (max) |
2 kHz |
| Cable Length (to sequence electronics, max) |
25 m |
| Dimensions (LxWxH) |
175 x 85 x 70 mm |
| Housing Length |
160 mm |
| Weight (approx) |
0.5 kg |
| Ambient Temperature (operation) |
0 to 55 °C |
| Ambient Temperature (storage/transport) |
-20 to +60 °C |
| Relative Humidity (operation) |
5 to 80% at 25 °C |
| Relative Humidity (storage) |
5 to 95% at 25 °C |
Installation & Setup Guidance
Installation of the Siemens 6FX2007-1AD03 handheld unit is straightforward. Connect the coiled cable to the control cabinet using the provided connector. Ensure the cable length does not exceed 25 meters from the sequence electronics. The magnetic latching feature allows secure attachment to metal surfaces. Verify that the emergency stop circuit is properly integrated with the system's safety relay. Use appropriate strain relief to prevent cable damage.
Maintenance & Reliability
Regular inspection of the cable for cuts or abrasion is recommended. Keep the connector contacts clean and dry. The Siemens 6FX2007-1AD03 is rated for operation in 0 to 55 °C ambient temperatures and up to 80% relative humidity, making it suitable for typical machine shop environments. Replacing older handheld units with this model enhances safety with its 2-channel emergency stop and 3-step enabling button, reducing downtime risks.
Compatibility & Integration
The Siemens 6FX2007-1AD03 is specifically designed for Sinumerik CNC control systems. It integrates seamlessly as a replacement for previous handheld units in this series. The connector handwheel with magnetic latching ensures reliable connection. For best compatibility, verify your Sinumerik control version and cable requirements with the product documentation.
Selection Guide & Purchasing Advice
Before purchasing the Siemens 6FX2007-1AD03, confirm that your application requires a 3.5-meter coiled cable and the 2-channel safety features. This unit is ideal for upgrading older handheld stations. For reliable sourcing, consider purchasing from ubest101, a trusted supplier of industrial automation parts. Ensure that the emergency stop and enabling button configurations match your system's safety circuit design.
