Product Introduction
The Siemens 6FX2001-5FP24 is a high-performance absolute value encoder designed for demanding industrial automation applications. This multiturn encoder delivers 27-bit digital resolution (8192 increments x 16384 revolutions) and operates with a PROFIBUS DP-V2 interface. It features a synchro flange with a 6 mm solid shaft, radial cable glands, and a robust design rated for IP64/IP67 protection. The encoder operates on 10-30 VDC and ensures precise position feedback even in harsh environments.
Technical Specifications Breakdown
The Siemens 6FX2001-5FP24 offers critical performance metrics that directly impact system reliability and accuracy:
-
Digital Resolution: 27 bit (8192 increments x 16384 rpms) – ensures fine position detection for precise motion control.
-
Accuracy: 79 arcseconds (with 8192 increments ± 1/2 LSB) – guarantees repeatable position feedback.
-
Transfer Rate: 12 Mbit/s via PROFIBUS DP – enables high-speed data exchange with controllers.
-
Operating Voltage: 10-30 VDC – offers flexibility for various power supplies.
-
Environmental Durability: Temperature range -40 to +85°C, vibration 100 m/s² (55-2000 Hz), and shock up to 2000 m/s² – built for tough industrial conditions.
These specs reduce downtime and maintenance costs, making the Siemens 6FX2001-5FP24 a cost-effective choice for long-term operations.
Application Scenarios
The Siemens 6FX2001-5FP24 excels in real-world applications where precise position feedback and robust communication are critical:
-
CNC Machining: The encoder’s 27-bit resolution and high accuracy ensure exact spindle positioning, improving part quality and reducing scrap.
-
Packaging Lines: With PROFIBUS DP-V2 support and slave-to-slave communication, the encoder integrates seamlessly into high-speed packaging systems for synchronized motion.
-
Material Handling: The rugged IP64/IP67 protection and wide temperature range allow reliable operation in dusty or wet environments, minimizing unplanned stops.
By choosing the Siemens 6FX2001-5FP24, you gain a reliable upgrade path for legacy systems, reducing total cost of ownership through extended service life.
Compatibility & Integration
The Siemens 6FX2001-5FP24 is designed for easy integration into PROFIBUS DP networks. It supports telegram 81, isochronous mode, and online parameterization. The encoder works with any PROFIBUS DP master and can be daisy-chained with up to 99 nodes. Its electrical connection uses a terminal block with address selector switch and bus terminating resistor, simplifying wiring. The encoder is CE and cULus approved, ensuring compliance with international standards.
Selection Guide & Purchasing Advice
When selecting the Siemens 6FX2001-5FP24, verify your system’s PROFIBUS DP compatibility and power supply voltage (10-30 VDC). Consider the synchro flange shaft diameter (6 mm) and mounting orientation. For replacement or new installations, ensure the cable length does not exceed 100 m at 12 Mbit/s (longer at lower rates). PLC Source PRO (ubest101) offers genuine Siemens encoders with fast shipping and technical support. Contact us for detailed specifications or custom requirements.
