Product Introduction
The Siemens 6ES7452-1AH00-0AE0 SIMATIC S7-400 Cam Control System FM 452 is an electronic unit designed for precise cam control in industrial automation. This module includes a configuration package on CD, enabling quick setup and integration. By leveraging advanced encoder interfaces and digital I/O, the 6ES7452-1AH00-0AE0 reduces downtime and maintenance costs, delivering a strong return on investment for motion-critical applications.
Technical Specifications Breakdown
The Siemens 6ES7452-1AH00-0AE0 operates on a 24 V DC supply with a maximum current consumption of 500 mA. It features 11 digital inputs and 16 digital outputs, all with rated voltage of 24 V DC. Power loss is typically 8.1 W, contributing to energy efficiency. The module supports multiple encoder types including incremental (symmetric/asymmetric) and absolute SSI encoders, with RS-422 interface for up to 1 MHz clock frequency. Key environmental specs include an operating temperature range of 0 °C to 55 °C and storage range of -40 °C to 70 °C. Dimensions are 25 mm x 290 mm x 210 mm, with a weight of approximately 650 g.
| Parameter |
Value |
| Supply Voltage |
24 V DC |
| Current Consumption, max. |
500 mA |
| Power Loss, typ. |
8.1 W |
| Digital Inputs |
11 |
| Digital Outputs |
16 |
| Encoder Interface |
Incremental (sym/asym), SSI absolute |
| Max Clock Frequency (SSI) |
1 MHz |
| Operating Temp. |
0…55 °C |
| Dimensions (W x H x D) |
25 x 290 x 210 mm |
| Weight |
650 g |
Application Scenarios
The Siemens 6ES7452-1AH00-0AE0 excels in packaging machinery, where precise cam profiles control cutting and sealing operations. It is also ideal for printing presses requiring synchronization of multiple axes. In material handling systems, the FM 452 provides reliable cam tracks for conveyor sorting. The module's ability to handle incremental and absolute encoders ensures accurate position feedback, minimizing scrap and reducing overall operational costs.
Installation and Setup Guidance
Mount the Siemens 6ES7452-1AH00-0AE0 on a standard DIN rail within the S7-400 rack. Use a 1x 48-pin front connector for wiring. Ensure the supply voltage is stable at 24 V DC. Configure the module using the provided software on CD, setting telegram length (13 or 25 bit) as needed. For encoder connections, adhere to cable length limits: 32 m for 5 V supply and 100 m for 24 V supply. Shield SSI encoder cables if exceeding 125 kHz to maintain signal integrity.
Selection Guide and Purchasing Advice
Before purchasing the Siemens 6ES7452-1AH00-0AE0, verify compatibility with your S7-400 CPU and available slot. The module requires a 48-pin front connector (not included). For assistance, contact ubest101 for reliable sourcing. This unit is an excellent choice for upgrading legacy cam controllers, offering improved accuracy and reduced maintenance.
