Product Introduction
When serial communication failures disrupt production, the Siemens 6ES7341-1AH01-0AE0 CP341 communication processor delivers reliable, high-speed data exchange for your SIMATIC S7-300 system. As a dedicated communication processor with an RS232C (V.24) interface, this module supports multiple protocols including 3964(R), ASCII, and RK512, ensuring compatibility with a wide range of industrial devices. The included configuration package on CD simplifies setup, reducing integration time.
Technical Specifications Breakdown
The Siemens 6ES7341-1AH01-0AE0 CP341 offers a comprehensive set of technical parameters designed for robust communication. Key specifications include:
-
Supply Voltage: Rated 24 V DC
-
Input Current: Max 200 mA from L+ supply; max 70 mA from backplane bus (5 V DC)
-
Power Loss: Max 4.8 W
-
Interface: 1 isolated RS232C (V.24) port, 9-pin sub D connector
-
Transmission Rate: 0.3 kbit/s to 76.8 kbit/s
-
Cable Length: Max 15 m
-
Integrated Protocol Drivers: 3964(R), ASCII, RK512 – all with max telegram length of 1,024 bytes
-
Transmission Speed (RS232): Up to 76.8 kbit/s with each protocol; note that 76.8 kbit/s is achievable only with half-duplex
-
Software Block: Max FB length in RAM: 5,500 bytes for data communication (send/receive)
-
Dimensions: 40 mm width, 125 mm height, 120 mm depth; weight approx. 300 g
These specifications ensure that the Siemens 6ES7341-1AH01-0AE0 handles demanding point-to-point serial links with minimal power consumption and space usage.
Installation & Setup Guidance
Proper installation of the Siemens 6ES7341-1AH01-0AE0 CP341 ensures reliable operation. Mount the module on a standard S7-300 rail. Connect power via the three screw-type terminals: L+, M, and GND. The RS232C interface uses a 9-pin sub D connector; ensure cable length does not exceed 15 m to maintain signal integrity. Use the included configuration CD to set protocol parameters and telegram lengths. For half-duplex operation at 76.8 kbit/s, verify that both devices support this mode. No special tools are required beyond standard screwdrivers and a communication cable.
Maintenance & Reliability
To maintain peak performance of the Siemens 6ES7341-1AH01-0AE0, perform periodic inspections of the RS232C connector and power terminals for corrosion or loose connections. Verify that the ambient temperature and humidity stay within the S7-300 system limits. Given the module’s low power loss (max 4.8 W), heat buildup is minimal, but ensure adequate airflow within the cabinet. The support for customer-specific, reloadable drivers allows easy firmware updates if communication requirements change, extending the module's service life.
Selection Guide & Purchasing Advice
Before purchasing, confirm that your controller is a SIMATIC S7-300 and that you require a point-to-point serial link using RS232C. The Siemens 6ES7341-1AH01-0AE0 is ideal for connecting to PLCs, drives, or third-party serial devices that support 3964(R), ASCII, or RK512 protocols. All necessary configuration software is included on the CD. For a reliable supply, consider visiting ubest101 – a trusted source for authentic industrial automation spares. Verify the part number matches your system requirements to avoid compatibility issues.
