Product Overview: Siemens 6ES7215-1AF40-0XB0 – Failsafe CPU for S7-1200F
The Siemens 6ES7215-1AF40-0XB0 is a compact, failsafe CPU from the SIMATIC S7-1200F series. It combines standard automation with integrated safety functions, making it ideal for applications requiring up to SIL3 (IEC 61508) or PLe (ISO 13849-1) safety integrity. This DC/DC/DC CPU offers 14 digital inputs, 10 digital outputs (0.5 A each), 2 analog inputs (0–10 V DC), and 2 analog outputs (0–20 mA DC). With 2 PROFINET ports, a program/data memory of 250 KB, and firmware V4.6, the 6ES7215-1AF40-0XB0 delivers high performance for both safety and non-safety control tasks. Its ability to run on STEP 7 V18 or higher and support for PROFIsafe, OPC UA, and MODBUS makes it a future-proof choice for upgrading legacy safety systems.
Technical Specifications Breakdown
Key parameters from the Siemens 6ES7215-1AF40-0XB0 datasheet include:
-
Supply voltage: 24 V DC (20.4–28.8 V), with reverse polarity protection
-
Work memory: 250 KB integrated; load memory 4 MB, expandable via SIMATIC Memory Card
-
Digital inputs: 14 integrated, 6 usable for HSC (high-speed counting up to 100 kHz)
-
Digital outputs: 10, with 4 high-speed pulse train outputs (100 kHz)
-
Analog inputs/outputs: 2 AI (0–10 V) and 2 AO (0–20 mA); 10-bit resolution
-
Communication: 2 PROFINET ports (RJ45), integrated switch; supports PROFINET IO Controller/Device, OPC UA Server, MODBUS, and PROFIBUS via add-on modules
-
Safety: Achieves SIL3 (IEC 61508) and PLe (ISO 13849-1); PROFIsafe enabled
-
Power consumption: Typical 12 W; max. 1.5 A with all expansions
-
Dimensions: 130 x 100 x 75 mm; weight approx. 500 g
These specs ensure the Siemens 6ES7215-1AF40-0XB0 can handle demanding real-time control and safety logic in a single device.
Industry Applications & ROI Benefits
The Siemens 6ES7215-1AF40-0XB0 is well-suited for machine safety, packaging lines, conveyor systems, and process automation where both standard and safety functions must coexist. By integrating safety directly into the CPU, this module reduces wiring complexity and cabinet space, lowering installation and maintenance costs. The built-in OPC UA server enables easy data exchange with higher-level systems, supporting Industry 4.0 initiatives. With 250 KB work memory and fast processing (0.08 µs/bit operation), the 6ES7215-1AF40-0XB0 handles complex logic without performance degradation. The long backup time (480 h typical) ensures program retention during power loss, minimizing downtime.
Compatibility & Integration
The Siemens 6ES7215-1AF40-0XB0 integrates seamlessly into a SIMATIC S7-1200F system. It supports up to 3 communication modules, 1 signal board, and 8 signal modules. Communication options include PROFINET (with MRP client for media redundancy), OPC UA (requires basic runtime license), MODBUS, and PROFIBUS (via CM 1243-5 or CM 1242-5). It also works with AS-Interface (CM 1243-2 required). The CPU can act as a PROFINET IO Controller or Device, handling up to 16 IO devices. With 34 reserved connections (expandable to 64), the 6ES7215-1AF40-0XB0 can communicate with multiple HMIs, SCADA systems, and other controllers simultaneously. Its web server and user-defined websites allow remote diagnostics.
Selection Guide & Purchasing Advice
When ordering the Siemens 6ES7215-1AF40-0XB0, ensure your power supply delivers 24 V DC (20.4–28.8 V) and that you have a SIMATIC Memory Card if additional load memory is needed. For safety applications, a STEP 7 Safety V18 or higher engineering package is required. The module is IP20 rated, so install it in a control cabinet. At PLC Source PRO (available via ubest101.myshopify.com), we stock genuine Siemens 6ES7215-1AF40-0XB0 units with full traceability. Verify your system compatibility before purchase, and consider adding a signal board or communication module for expanded I/O. This CPU is an excellent choice for upgrading older S7-1200 or third-party safety systems, offering reduced lifecycle costs and enhanced connectivity.
