Product Introduction
When upgrading ET200SP systems, the Siemens 6ES7193-4JB00-0AA0 Industrial Automation Module provides a robust interface connection. This connector, female 2x2-pole, is designed for interface modules like KP32F and PN-PN coupler. It replaces older connectors with a grid size of 5.08 mm cage clamp technology that is internally bridged and color-coded. Each packing unit contains 10 pieces.
Technical Specifications
| Parameter |
Value |
| Supply Voltage Type |
DC |
| Rated Supply Voltage |
24 V |
| HMI-Side Number of Pins |
2 (outgoing internally jumpered, color-coded) |
| Device-Side Number of Pins |
4 (female, spring-loaded terminals 0.75 mm²) |
| CE Mark |
Yes |
| RoHS Conformity |
Yes |
| China RoHS |
Yes |
| Storage Temperature |
-20 °C to 70 °C |
| Housing Material |
Plastic |
| Dimensions (W x H x T) |
10 mm x 22 mm x 25 mm |
| Delivery Quantity |
10 pieces per packing unit |
Industry Applications
This Siemens 6ES7193-4JB00-0AA0 connector is ideal for interfacing SIMATIC HMI devices with ET200SP distributed I/O systems. It ensures reliable signal transmission in factory automation, process control, and machine building. The 24 V DC supply makes it compatible with standard industrial power rails.
Installation & Setup Guidance
Mount the Siemens 6ES7193-4JB00-0AA0 by plugging it directly into the SIMATIC HMI device. The spring-loaded terminals accept 0.75 mm² wire for secure connection. The cage clamp mechanism provides vibration-resistant termination. No special tools are required; simply insert the wires and close the clamp.
Compatibility & Integration
The Siemens 6ES7193-4JB00-0AA0 is designed for ET200SP systems, specifically for interface modules KP32F and PN-PN coupler. It works with SIMATIC HMI panels and other 24 V DC devices. The female 2x2-pole design ensures proper mating with the device-side interface.
Selection Guide & Purchasing Advice
Before ordering the Siemens 6ES7193-4JB00-0AA0, confirm your system uses ET200SP distributed I/O with a compatible interface module. This connector comes in a pack of 10, color-coded for easy identification. For reliable supply, consider ubest101 as your source for genuine Siemens components. Ensure your HMI device accepts this connector type.
