Product Introduction
When reliable, high-current digital output is critical in safety applications, the Siemens 6ES7136-6RA00-0BF0 provides a fail-safe solution. This digital output module belongs to the SIMATIC ET 200SP series and is designed for demanding industrial environments. With a product type designation of F-RQ 1x24VDC/24...230VAC/5A, the Siemens 6ES7136-6RA00-0BF0 handles both DC and AC loads up to 5 A. Its wide voltage range and robust design ensure long-term cost benefits by reducing the need for multiple modules.
Technical Specifications Breakdown
The Siemens 6ES7136-6RA00-0BF0 delivers precise control with the following key parameters derived from its datasheet:
| Specification |
Value |
| Supply Voltage Type |
24 VDC |
| Rated Coil Voltage |
24 V |
| Permitted Voltage Range (DC) |
20.4 V to 28.8 V |
| Power Consumption from Backplane Bus |
100 mW |
| Typical Power Loss |
1 W |
| Number of Outputs |
1 |
| Max. Resistive Load Switching Capacity |
5 A |
| Max. Lamp Load Switching Capacity |
25 W |
| Address Space per Module (Input) |
1 byte |
| Hardware Product Version |
01 |
| Firmware Version |
V1.0.0 |
| I&M Data |
I&M0 to I&M3 |
These specifications show the Siemens 6ES7136-6RA00-0BF0 is optimized for safety circuits requiring high current switching and voltage flexibility.
Real-World Applications
- Safety shutdown systems in manufacturing lines where the 6ES7136-6RA00-0BF0 reliably disconnects power under fault conditions.
- Motor starter control for AC motors up to 5 A, leveraging the wide voltage range (24-230 VAC).
- Industrial lighting control with lamp loads up to 25 W, using the high switching capacity.
Each application benefits from the long-term reliability and reduced inventory costs offered by a single module supporting multiple voltages.
Installation & Setup Guidance
The Siemens 6ES7136-6RA00-0BF0 mounts on a standard DIN rail. Ensure the supply voltage stays within the permitted range (20.4-28.8 VDC) for stable operation. Connect the load to the output terminal and verify wiring polarity for DC applications. The module integrates seamlessly into an ET 200SP station using the backplane bus for power and communication.
Compatibility & Integration
This module works with SIMATIC ET 200SP systems. Engineering can be done using STEP 7 TIA Portal (as of V13) or STEP 7 V5.5 SP4 and higher. The Siemens 6ES7136-6RA00-0BF0 supports I&M data (I&M0 to I&M3) for identification and maintenance, simplifying system integration.
Selection Guide & Purchasing Advice
Before purchasing, verify your system requires a fail-safe digital output module with the given voltage and current ratings. The Siemens 6ES7136-6RA00-0BF0 is a genuine Siemens part available from PLC Source PRO (formerly ubest101). Ensure you have compatible backplane and controller for the ET 200SP series.
