Product Introduction
The Siemens 6EP1334-3BA00 is a robust stabilized power supply from the SITOP PSU200M series. It delivers a steady 24V DC output at 10A, accepting a wide AC input range of 120/230-500V. Designed for demanding industrial environments, this module ensures reliable power for PLCs, DCS systems, drives, and sensors. With an efficiency of approx. 87%, the 6EP1334-3BA00 minimizes energy losses and operational costs, making it a cost-effective choice for continuous-duty applications.
Technical Specifications Breakdown
Key performance parameters of the Siemens 6EP1334-3BA00 include:
-
Input voltage: 120/230-500V AC (wide-range, 85-264V at 120V nominal, 176-550V at 230-500V nominal).
-
Output: 24V DC, adjustable 24-28.8V; rated current 10A (0-10A continuous).
-
Efficiency: Typ. 87% at rated output, reducing heat dissipation and energy costs.
-
Mains buffering: Min. 25 ms at rated current, ensuring ride-through during brief interruptions.
-
Protection: Short-circuit proof with current limitation typ. 12A; enduring short circuit current typ. 12A.
The static voltage tolerance is ±3%, and the residual ripple (peak-peak) is max. 50 mV, providing clean power for sensitive digital loads. The unit features a green LED indicator for 24V OK status.
Industry Applications
The Siemens 6EP1334-3BA00 is ideal for powering 24V control circuits in automation panels, conveyor systems, and process control stations. For example, in a packaging line, it supplies PLC I/O modules and sensors with stable voltage, reducing false triggers and downtime. Its wide input range (120-500V AC) makes it suitable for global installations with varying line voltages, while the 25 ms buffering helps maintain operation through dips. The ability to parallel up to two units for enhanced power (up to 20A) supports scalability for growing systems.
Installation & Setup Guidance
Mount the 6EP1334-3BA00 on a DIN rail (TS35) using the integrated clip. The housing width is 90 mm, depth 125 mm, and height 125 mm (with an installation height of 225 mm including clearance). Use screw terminals for electrical connections: L, N, and PE for input; + and - for output. Ensure proper ventilation as the unit dissipates approx. 36 W at full load. The operating ambient temperature range is -25 to +70 °C, making it suitable for most industrial enclosures. No wall mounting is supported; only DIN rail mounting is allowed.
Selection Guide & Purchasing Advice
Before ordering, verify that your system requires a 24V DC, 10A stabilized power supply. The Siemens 6EP1334-3BA00 is a genuine SITOP unit, ensuring compatibility with Siemens I/O and controllers. For applications needing higher current, two units can be paralleled for up to 20A. Ensure the input voltage range matches your facility (120V, 230V, or 500V AC). This power supply features protection class IP20, so it is intended for indoor, controlled environments. For reliable sourcing, consider purchasing from PLC Source PRO (formerly ubest101) to guarantee genuine Siemens parts and fast delivery.
