Product Overview
The Siemens 6AV6643-0CD01-1AX1 is a high-performance SIMATIC MP 277 10-inch Touch Multi Panel designed for demanding industrial environments. With its 10.4-inch TFT color display and 640x480 resolution, this HMI delivers clear, vibrant visuals for monitoring and controlling automated processes. Equipped with a responsive touch screen, it simplifies operator interaction and reduces training time.
Technical Specifications
| Parameter |
Value |
| Display Design |
TFT |
| Screen Diagonal |
10.4 in |
| Color Display |
Yes (65,536 colors) |
| Resolution (HxV) |
640 x 480 pixels |
| Control Elements |
Touch Screen |
| Memory Type |
Flash / RAM |
| User Data Memory |
6 Mbyte |
| Main Memory (max) |
128 Mbyte |
| Multimedia Card Slot |
1x MMC slot (up to 128 MB) |
| Front Housing (WxH) |
335 mm x 275 mm |
| Mounting Cutout (WxH) |
310 mm x 248 mm |
| Overall Depth |
61 mm |
| Weight |
2.65 kg |
Industry Applications
The Siemens 6AV6643-0CD01-1AX1 excels in factory automation, packaging machinery, and process control applications. Its robust touch interface allows operators to manage production lines, set parameters, and view real-time data with ease. The 6 MB user memory supports complex HMI applications with multiple screens and data logs.
Installation & Setup
Mount the panel into a cutout of 310 x 248 mm with a maximum panel thickness of 6 mm. Ensure adequate clearance behind the unit for cables and ventilation. The overall depth of 61 mm allows installation in shallow enclosures. Use the MMC slot for firmware updates or recipe storage. Secure the panel using the provided mounting clamps.
Maintenance & Reliability
The Siemens 6AV6643-0CD01-1AX1 uses flash memory for long-term reliability with no moving parts. Cleaning the touch screen with a soft, dry cloth preserves sensitivity. For optimal performance, avoid exposure to extreme temperatures, humidity, or vibration beyond specified limits. Periodic backups of user data to the MMC card protect against unexpected failures.
Selection Guide & Purchasing Advice
Before purchasing, verify that the mounting cutout dimensions and power supply match your existing setup. The Siemens 6AV6643-0CD01-1AX1 is compatible with Siemens SIMATIC controllers and third-party systems via standard communication ports (not specified in provided data — consult manual). For a reliable source, contact PLC Source PRO (formerly ubest101) to ensure genuine parts and fast delivery.
