Product Overview
When production downtime disrupts your workflow, the Siemens 6AV6643-0AA01-1AX0 delivers reliable human-machine interface performance with a long-lasting 60,000-hour backlight. This operator interface panel, part of the SIMATIC series, is designed for localized control and monitoring tasks. Its 5.7-inch TFT display with 320 x 240 pixel resolution and resistive touch technology ensures clear, intuitive interaction.
Technical Specifications
The Siemens 6AV6643-0AA01-1AX0 offers robust specifications for demanding industrial environments. Below are the key parameters directly from the product data:
| Specification |
Value |
| Manufacturer |
Siemens |
| Product Type |
Operator Interface Panel (TP277) |
| Product Line |
SIMATIC |
| Part Number |
6AV6643-0AA01-1AX0 |
| UPC |
662643209563 |
| Weight |
0.94 lbs (0.43 kg) |
| Display Technology |
5.7-inch TFT with touch functionality |
| Screen Resolution |
320 x 240 pixels (QVGA) |
| Color Capability |
256-color palette |
| Backlight Durability |
Estimated 60,000-hour lifespan at 25°C |
| Touch Interface |
Resistive analog touch panel |
| User Storage Capacity |
4 MB Flash memory |
| Processing Unit |
32-bit RISC architecture |
| Connectivity Ports |
1x RS422, 1x RS485, 1x Ethernet (RJ45), 1x USB |
| Supported Communication |
Compatible with PROFINET, PROFIBUS, MODBUS, TCP/IP |
| Temperature Range |
Functional between 0°C and 50°C |
| Enclosure Protection |
IP65-rated front panel, IP20 rear panel |
| Physical Dimensions |
212 mm (W) x 156 mm (H) x 45 mm (D) |
Industry Applications
The Siemens 6AV6643-0AA01-1AX0 excels in manufacturing lines, packaging machinery, and material handling systems. Its 256-color display and resistant touch panel provide clear operator feedback even in harsh conditions. The long backlight life reduces replacement frequency, delivering cost savings over the product lifecycle.
Integration and Connectivity
With support for PROFINET, PROFIBUS, MODBUS, and TCP/IP, the Siemens 6AV6643-0AA01-1AX0 integrates seamlessly into existing automation networks. The Ethernet (RJ45) and serial ports (RS422/RS485) allow connection to PLCs, drives, and sensors. This compatibility minimizes upgrade complexity and protects your current investments.
Buying Guide
Before purchasing the Siemens 6AV6643-0AA01-1AX0, verify that your system requires a 24 VDC power supply (not included) and that the panel fits your enclosure cutout (212 x 156 mm). For reliable sourcing, PLC Source PRO (ubest101) offers tested, authentic units with fast shipping. Check stock and lead times before ordering.
