Product Introduction
With a 22-inch widescreen TFT display and 16 million colors, the Siemens 6AV2124-0XC02-0AX1 SIMATIC HMI TP2200 Comfort provides clear visualization for complex processes. This touch-operated panel replaces older HMI models, offering enhanced resolution, faster configuration, and seamless integration into modern industrial networks. Its robust design and extensive connectivity make it ideal for upgrading existing control systems.
Technical Specifications Breakdown
The Siemens 6AV2124-0XC02-0AX1 delivers impressive performance metrics:
-
Display: 21.5" TFT, 1920x1080 pixels, 16,777,216 colors
-
Backlight MTBF: 30,000 hours at 25°C, dimmable (0-100%)
-
Processor: X86 architecture with 24 MB user memory
-
Power input: 24 V DC, 1.7 A, 41 W typical
-
Interfaces: 2x Industrial Ethernet (switch), 1x RS 485/422, 2x USB 2.0, 2x SD card slots
-
Protocols: PROFINET, PROFIBUS, EtherNet/IP, Modbus, MPI, OPC UA Client/Server
-
Enclosure: IP65 front, IP20 rear, NEMA 4/4X front
Industry Applications
This HMI excels in demanding environments such as automotive assembly lines, food and beverage processing, and packaging machinery. The large, high-resolution screen enables operators to monitor multiple process parameters simultaneously, while the analog-resistive touch ensures reliable operation even with gloved hands. Its 40 direct keys allow quick access to critical controls, reducing reaction time in high-speed production lines.
Compatibility & Integration
The Siemens 6AV2124-0XC02-0AX1 integrates seamlessly with Siemens controllers (S7-1200, S7-1500, S7-300/400, LOGO!, WinAC) and supports third-party devices via EtherNet/IP, Modbus TCP/IP, and OPC UA. It can also communicate with Allen‑Bradley, Mitsubishi, and Omron PLCs. The panel features two independent Ethernet ports with integrated switch for network redundancy, and supports media redundancy protocol (MRP) for high-availability topologies.
Selection Guide & Purchasing Advice
Before purchasing, verify your mounting cutout dimensions: 542 mm width x 362 mm height. The panel requires a 24 V DC supply rated for at least 1.7 A. The unit ships with a weight of 6.7 kg and overall depth of 73.2 mm. For configuration, you need WinCC Comfort V14 SP1 or higher. PLC Source PRO (ubest101) stocks this genuine module along with compatible accessories like the SIMATIC HMI SD memory card up to 2 GB and USB sticks. Contact us to confirm stock and shipping options.
