Product Overview
Upgrading your industrial HMI? The Siemens 6AV2124-0JC01-0AX0 SIMATIC HMI TP900 Comfort panel delivers modern touch operation, robust connectivity, and powerful visualization capabilities. This 9-inch widescreen TFT display replaces older panels with a feature-rich interface supporting 16 million colors, PROFINET and MPI/PROFIBUS DP interfaces, and a 12 MB configuration memory. Pre-installed with Windows CE 6.0 and configurable via WinCC Comfort V11, this Siemens 6AV2124-0JC01-0AX0 module is engineered for seamless integration in demanding automation environments.
Key Technical Specifications
The Siemens 6AV2124-0JC01-0AX0 packs impressive specs into a compact form factor:
-
Display: 9-inch TFT, 800 x 480 pixels, 16,777,216 colors, dimmable backlight (MTBF 80,000 h)
-
Processor: X86 architecture
-
Memory: 12 MB user data, Flash + RAM
-
Interfaces: 1 Industrial Ethernet (2-port switch), 1 RS 485/422, 2 USB 2.0, 1 Mini USB, 2 SD slots
-
Protocols: PROFINET IRT, PROFIBUS, EtherNet/IP, MPI, MODBUS, OPC UA Client/Server
-
Power: 24 V DC (19.2–28.8 V), 0.75 A, 18 W
-
Environmental: IP65 front, IP20 rear; operating temp 0–50°C (vertical); ATEX Zone 2/22, IECEx, cULus, marine approvals
-
Operating System: Windows CE 6.0
Applications & Real-World Use
Ideal for replacing dated HMIs on packaging lines, assembly stations, and process control skids, the Siemens 6AV2124-0JC01-0AX0 excels in applications requiring multi-protocol connectivity and high-resolution visualization. For example, in a bottling plant, it can display real-time production data while communicating via PROFINET IRT to a S7-1500 controller and via MODBUS to a variable frequency drive. The 32 runtime languages and 500 configurable images make it suitable for global deployments.
Compatibility & Integration
The Siemens 6AV2124-0JC01-0AX0 connects to a wide range of controllers via Ethernet/IP, PROFIBUS, MODBUS, MPI, and OPC UA. Compatible with Siemens S7-1200/1500/300/400, SIMOTION, SINUMERIK, and third‑party brands like Allen‑Bradley and Mitsubishi. Support for WinCC Comfort/Advanced/Professional (TIA Portal) ensures straightforward integration into existing Siemens architecture.
Maintenance & Reliability
With an 80,000-hour backlight MTBF and robust IP65 front, the Siemens 6AV2124-0JC01-0AX0 minimizes downtime. Routine checks include inspecting cable connections and ensuring ambient temperature stays within 0–50°C (vertical orientation). The retentive hardware clock (6‑week backup) preserves time setting across power cycles. No active cooling required; the 35° maximum tilt angle allows flexible mounting.
Selection Guide & Purchasing Advice
Before purchasing the Siemens 6AV2124-0JC01-0AX0, verify your project software version (WinCC Comfort V11 or higher) and mounting cutout dimensions (251 x 166 mm). For optimal performance, use a 24 V DC power supply with a 0.75 A rating. This module does not include a memory card – order separately if needed (SD up to 2 GB, USB up to 16 GB). PLC Source PRO (ubest101) stocks this HMI with fast shipping and technical support to ensure a smooth upgrade.
