Product Overview
In demanding industrial environments, reliable operator control is essential. The Siemens 6AV2123-2GB03-0AX0 KTP700 Basic HMI delivers an intuitive interface with a 7-inch widescreen TFT display (800x480 pixels, 65536 colors) and LED backlighting (MTBF 20,000 h at 25°C). This Industrial Automation Module combines key operation and analog-resistive touch, making it ideal for machine builders and system integrators seeking long-term value. With PROFINET, EtherNet/IP, and MODBUS TCP/IP support, the 6AV2123-2GB03-0AX0 integrates seamlessly into existing networks.
Technical Specifications Breakdown
Key parameters of the Siemens 6AV2123-2GB03-0AX0 underscore its robust design:
-
Display: 7-inch TFT widescreen, 154.1×85.9 mm, 65,536 colors, LED backlight dimmable.
-
Supply Voltage: 24 V DC (19.2–28.8 V), rated current 230 mA, typical power 5.5 W.
-
Processor & Memory: ARM processor; flash and RAM; 10 Mbyte user data memory.
-
Interfaces: 1 Industrial Ethernet, 1 USB (up to 16 GB), PROFINET, EtherNet/IP, MODBUS TCP/IP.
-
Environmental: IP65 front, IP20 rear; operating temperature 0–50°C (vertical); storage -20 to 60°C.
-
Weight: 780 g (without packaging), 990 g (with packaging).
These specifications contribute to reduced downtime and energy savings, aligning with a cost-benefit approach for B2B users.
Compatibility & Integration
The Siemens 6AV2123-2GB03-0AX0 supports multiple protocols for flexible connectivity: PROFINET, TCP/IP, DHCP, SNMP, DCP, LLDP, and MODBUS (Modicon TCP/IP). It connects directly to SIMATIC controllers (S7-1200, S7-1500, S7-300/400, S7-200, LOGO!, WinAC) as well as Allen-Bradley (EtherNet/IP), Mitsubishi (MC TCP/IP), and Modicon (Modbus TCP/IP). Integration with TIA Portal via WinCC Basic V13 or higher simplifies configuration and reduces engineering time.
Installation & Setup Guidance
Mount the Siemens 6AV2123-2GB03-0AX0 in a vertical position with a maximum inclination of 35° without external ventilation. The panel supports portrait and landscape orientations. Cutout dimensions: 198 mm (width) × 142 mm (height). Connect a 24 V DC supply within 19.2–28.8 V; rated current 230 mA. Use the USB port for data transfer or external storage. The device does not support wall mounting or direct mounting—plan for panel installation. Follow standard EMC guidelines (Class A industrial); ensure proper grounding to minimize interference.
Selection Guide & Purchasing Advice
Before purchasing the Siemens 6AV2123-2GB03-0AX0, verify your system voltage and communication requirements. This HMI is pre-configured with open-source software (included on CD). For projects needing more than 10 runtime languages or additional archives, note the device supports up to 50 recipes and 800 variables. PLC Source PRO offers genuine Siemens modules with full traceability. For any customization or bulk orders, contact ubest101 via the store link to discuss your specific needs.
