Product Overview
When upgrading or replacing communication modules in Modicon systems, the Schneider TSXSCM2116 offers a reliable solution. This dedicated communication module supports RS232 IS/UTWAY HD/UNITE protocols, ensuring seamless integration and connectivity. Designed for robust performance across diverse environments, the TSXSCM2116 is an ideal choice for modernizing your automation infrastructure.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Line |
Modicon |
| Part Number |
TSXSCM2116 |
| Weight |
2.81 lbs (1.28 kg) |
| Communication Protocols |
RS232 IS/UTWAY HD/UNITE |
| Ambient Operating Temperature |
0 to 55 °C |
| Ambient Transportation Temperature |
-40 to 70 °C |
| Ambient Storage Temperature |
-25 to 55 °C |
| Relative Humidity |
5 to 95% without condensation |
| Module Dimensions (approx.) |
100 mm x 225 mm x 235 mm |
| Package Dimensions (1 PCE) |
10 cm x 22.5 cm x 23.5 cm |
These specifications demonstrate the reliability of the Schneider TSXSCM2116.
Compatibility & Integration
The TSXSCM2116 integrates seamlessly with Modicon automation systems. Its support for RS232 IS/UTWAY HD/UNITE protocols enables direct communication with compatible controllers and peripherals. When replacing an older communication module, verify that your system's backplane and firmware support the TSXSCM2116. This module ensures reliable data transfer and reduces downtime during upgrades.
Replacement & Upgrade Considerations
For facilities looking to modernize their Modicon network, the Schneider TSXSCM2116 provides a straightforward upgrade path. Its compact form factor fits existing racks, and its enhanced protocol support improves communication reliability. Consider using this module to replace outdated units that no longer meet performance requirements. The TSXSCM2116 withstands temperature extremes from -40°C to 70°C during transport and storage, ensuring it arrives in optimal condition.
Selection Guide
Before purchasing the TSXSCM2116, confirm compatibility with your existing system hardware. Check the power supply requirements and backplane slot availability. For expert assistance, visit PLC Source PRO at ubest101.myshopify.com. We stock a wide selection of Schneider automation spares to support your upgrades.
