Product Overview
The Schneider TSXRKN5 is a short extension rack designed to expand the capacity of Modicon automation systems. Supporting up to five positions, this compact module enables flexible I/O configurations in material handling, packaging, and textile applications. As a genuine Schneider Electric component, the TSXRKN5 ensures seamless integration and robust performance in demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Type |
Short Extension Rack |
| Product Line |
Modicon |
| Part Number |
TSXRKN5 |
| Number of Supported Positions |
5 Positions |
| Application Support |
Material Handling, Packaging, Textiles |
| Operating Temperature |
0 to 40 °C |
| Maximum Operating Humidity |
80% RH (non-condensing) |
| Maximum Storage Humidity |
80% RH (non-condensing) |
| Maximum Operating Altitude |
1000 m (without derating) |
| Storage Temperature |
0 to 50 °C |
Industrial Applications
The Schneider TSXRKN5 excels in three primary sectors:
-
Material Handling: Supports conveyor systems and sorting equipment with reliable extension capability.
-
Packaging: Enables modular expansion for packaging line controllers.
-
Textiles: Provides flexible I/O mounting for textile machinery.
Its 5-position design makes it ideal for upgrading older fixed racks, giving engineers the versatility to add modules without replacing the entire backplane.
Installation & Setup Guidance
Mount the TSXRKN5 in a clean, dry cabinet within the specified operating temperature range of 0 to 40 °C. Ensure adequate airflow around the rack to prevent overheating. The rack accepts standard Modicon modules into its five slots – simply slide each module into the guide rails and secure with the locking clips. Use appropriate cabling for communication with the controller.
Maintenance & Reliability
To maximize service life, inspect the rack quarterly for dust accumulation and verify that all connections are tight. The TSXRKN5 operates reliably up to 80% relative humidity (non-condensing) and at altitudes up to 1000 m without derating. When storing, keep the unit between 0 and 50 °C in a low-humidity environment. Routine checks of the backplane contacts can prevent intermittent faults.
Selection Guide & Purchasing Advice
Before ordering, verify that your existing Modicon system supports the TSXRKN5 short extension rack. Confirm the physical dimensions are compatible with your enclosure. For guaranteed authenticity and reliable delivery, consider purchasing from PLC Source PRO (formerly ubest101), a trusted supplier of industrial automation spares. Ensure you have the necessary mounting hardware and compatible power supply modules to complete the installation.
