Product Introduction
The Schneider TSXPSY5520MC is a robust power supply module designed for the Modicon Premium automation platform. In industrial environments where power disturbances are common, this module provides reliable power conversion with comprehensive protection. It supports a primary voltage range of 24...48 V DC (19.2...60 V) and delivers up to 50 W of total useful secondary power.
Technical Specifications Breakdown
Key parameters of the Schneider TSXPSY5520MC include:
-
Input Current: ≤1500 mA at 48 V, ≤3000 mA at 24 V
-
Inrush Current: 15 A at both 24 V and 48 V
-
Protection Types: Internal fuse (5A time-delayed), overload, overvoltage, and short-circuit protection on secondary circuit
-
Immunity to Microbreaks: 1 ms, ensuring operation during brief power interruptions
-
Dielectric Strength: 2000 V primary/earth and primary/secondary
-
Insulation Resistance: ≥10 MΩ
-
Operating Temperature: -10°C to 60°C
-
Local Signalling: Green LED for presence of voltages (OK), red LED for battery fault (BAT)
These specifications make the Schneider TSXPSY5520MC a reliable choice for maintaining uptime in critical automation systems.
Industry Applications
The Schneider TSXPSY5520MC excels in manufacturing lines, process control, and machine automation where power stability is crucial. Its immunity to microbreaks prevents controller resets during short voltage dips, while the integrated fuses and protection circuits safeguard downstream modules. In a typical assembly line, this module can power PLC racks and I/O modules, reducing downtime caused by power anomalies.
Maintenance & Reliability
To ensure consistent performance, periodic inspection of the LED indicators is recommended. A green OK LED confirms normal operation, while a red BAT LED signals battery issues. The module's conformal coating (Humiseal 1A33) and IP20 protection make it suitable for controlled industrial environments. With proper care, the Schneider TSXPSY5520MC offers long service life, minimizing total cost of ownership.
Selection Guide & Purchasing Advice
Before purchasing the Schneider TSXPSY5520MC, verify that your system's voltage requirements match the 24...48 V DC input range. Also confirm that the secondary power demands (19 W at 24 V DC, 35 W at 5 V DC) do not exceed the module's capacity. For reliable sourcing, consider PLC Source PRO (available at ubest101.myshopify.com) as a trusted supplier of genuine automation spares.
