Product Introduction
When maintaining reliable power for your Modicon control system, the Schneider TSXPSY1610 Industrial Automation Module provides a robust solution. This power supply module operates at a primary input voltage of 24 V DC, accepting a range from 19.2 to 30 V, and is designed to deliver consistent performance in demanding industrial environments. Part of the Modicon product line, the TSXPSY1610 ensures stable operation with a maximum input current of 1500 mA at 24 V and handles inrush currents up to 100 A, making it an ideal choice for critical automation applications.
Technical Specifications
The Schneider TSXPSY1610 offers a range of parameters that ensure reliability and efficiency. Below are the key specifications from the manufacturer:
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Line |
Modicon |
| Part Number |
TSXPSY1610 |
| Weight |
1.00 lbs (0.45 kg) |
| Primary Voltage |
24 V DC (19.2...30 V) |
| Input Current |
≤ 1500 mA at 24 V |
| Inrush Current |
100 A at 24 V |
| I²t on Activation |
12.5 A².s |
| Relative Humidity Operating |
10…95 % without condensation |
| Relative Humidity Storage |
5…95 % without condensation |
| Operating Altitude |
0...6561.68 ft (0...2000 m) |
| Protective Treatment |
TC (Thermal Classification) |
| IP Degree of Protection |
IP20 |
| Pollution Degree |
2 |
Industry Applications
The Schneider TSXPSY1610 excels in factory automation, process control, and material handling systems where a stable 24 V DC supply is critical. Its wide humidity tolerance (10–95% without condensation) makes it suitable for environments with varying moisture, such as food processing or packaging lines. The module's IP20 rating and pollution degree 2 ensure reliable operation in controlled industrial settings with occasional non-conductive pollutants. By choosing this power supply, you reduce downtime and extend the life of your Modicon system.
Installation and Setup Guidance
For optimal performance, mount the Schneider TSXPSY1610 in a clean, dry enclosure away from excessive vibration. Ensure the ambient temperature remains within standard industrial limits and that air flow is adequate for the thermal classification (TC). The IP20 rated housing requires no special sealing, but avoid exposure to dust or liquids. Connect the 24 V DC input source with proper polarity and use appropriate fusing to protect against the 100 A inrush current. Refer to the Modicon system manual for exact wiring and bus connection details.
Maintenance and Reliability
The Schneider TSXPSY1610 is designed for long service with minimal maintenance. Regularly inspect the module for dust accumulation on cooling surfaces and ensure connectors remain tight. The protective treatment (TC) helps endure thermal stress, so periodic checks of ambient temperature and humidity are sufficient. Operating within the specified altitude and humidity ranges ensures maximum reliability. This module's robust construction translates to lower lifecycle costs and reduced unplanned downtime.
Selection Guide and Purchasing Advice
When purchasing the Schneider TSXPSY1610, verify that your system requires a 24 V DC input supply at up to 1500 mA. This module is a direct replacement for older Modicon power supplies and integrates seamlessly. For additional support or to order, visit ubest101 (the PLC Source PRO store) for genuine parts and fast shipping. Always confirm compatibility with your specific Modicon backplane before ordering.
