Product Overview
The Schneider TSXP572634 Unity processor is designed for advanced control systems requiring high I/O density and flexible networking. Part of the Modicon product line, this processor supports up to 1024 discrete I/O points and 80 analog I/O channels, making it an ideal choice for replacing legacy controllers or expanding existing automation architectures. With a double module format and Ethernet 10BASE-T/100BASE-TX connectivity, the TSXP572634 integrates seamlessly into modern industrial networks.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Line |
Modicon |
| Part Number |
TSXP572634 |
| Product |
Unity processor |
| Discrete I/O Capacity |
1024 I/O |
| Analog I/O Capacity |
80 I/O |
| Ethernet Port |
10BASE-T/100BASE-TX |
| Current Consumption |
1650 mA at 5 V DC |
| Module Format |
Double |
| Operating Temperature |
0 to 60 °C |
| Storage Temperature |
-25 to 70 °C |
| IP Protection |
IP20 |
| Rack Configuration |
8 racks (12 slots) / 16 racks (4/6/8 slots) |
| Max Slots |
≤ 128 |
Industry Applications
The Schneider TSXP572634 excels in manufacturing lines, water treatment plants, and material handling systems. Its 1024 discrete I/O capacity handles large sensor arrays and actuator banks, while the 80 analog I/O channels manage continuous process variables such as flow, pressure, and temperature. The Ethernet port enables seamless connection to SCADA systems and remote monitoring. Upgrading from older PLCs to the TSXP572634 reduces wiring complexity and improves data throughput.
Installation and Setup
Mount the Schneider TSXP572634 in a standard 19-inch rack with the double module format. Connect to 5 V DC power supply providing 1650 mA. Use shielded Ethernet cables for 10BASE-T/100BASE-TX connections. Configure the Unity processor via Schneider’s Unity Pro software. Ensure adequate ventilation for operating temperatures between 0 and 60 °C. The IP20 rating requires installation in a clean, dry enclosure.
Compatibility and Integration
The TSXP572634 integrates with Modicon BMX/Premium racks and supports up to 128 slots across multiple rack configurations. It communicates over Ethernet TCP/IP, allowing connection to modern HMIs and drives. For legacy system upgrades, this processor can replace older Unity processors without major reconfiguration, preserving existing I/O modules.
Selection Guide
Before purchasing the Schneider TSXP572634, verify your rack type, power supply capacity, and Ethernet network requirements. This processor suits applications needing high discrete I/O counts and moderate analog capabilities. For assistance, contact PLC Source PRO, your trusted automation parts supplier. We ensure genuine components and fast delivery.
