Product Introduction
When expanding your industrial automation network, the Schneider TSXP571634M communication module delivers robust connectivity for TSX Micro PLC systems. This module accommodates up to two communication module connections and provides integrated Ethernet TCP/IP via an RJ45 port as well as a serial link using two female mini-DIN RS485 interfaces operating at 19.2 kbit/s. Designed for reliability, the Schneider TSXP571634M ensures seamless data exchange in demanding environments.
Technical Specifications Breakdown
The Schneider TSXP571634M offers a rich set of technical capabilities. Key specifications include:
- Communication Module Processor Capacity: 2 modules
- Discrete I/O Processor Capacity: 512 I/O
- Analogue I/O Processor Capacity: 24 I/O
- Internal RAM: 96 KB data (expandable via PCMCIA card to 224 KB program + 96 KB data)
- Execution Time per Instruction: 0.19 µs Boolean without PCMCIA card
- Current Consumption: 1650 mA at 5 V DC
These parameters make the Schneider TSXP571634M suitable for applications requiring fast processing and moderate I/O counts.
Real-World Applications
This communication module excels in machine control systems where multiple remote devices need integration via Ethernet and serial links. For example, in a packaging line, the Schneider TSXP571634M can connect a central PLC to operator panels and sensors. In process automation, it enables reliable data exchange between controllers and supervisory systems. Its support for up to 512 discrete I/O and 24 analog I/O covers a wide range of industrial needs.
Installation & Setup Guidance
Mount the Schneider TSXP571634M in a TSX Micro PLC rack using the appropriate slots. Ensure the 5 V DC supply can deliver at least 1650 mA. Connect the Ethernet cable to the RJ45 port and the serial link cable to the female mini-DIN RS485 connectors. Configure communication parameters via Unity Pro software, setting baud rate to 19.2 kbit/s for the serial link. Verify status via front panel LEDs (RUN, ERR, TX, RX).
Maintenance & Reliability
Periodically inspect the Schneider TSXP571634M for debris on connectors and ensure ventilation is unobstructed. The module operates within 0 to 60 °C ambient temperature and up to 2000 m altitude. Check the status LEDs to identify potential issues early. Regular firmware updates via Unity Pro can enhance performance and security.
Compatibility & Integration
