Product Introduction
When your existing PLC processor limits expansion, the Schneider TSXP571634 Unity Processor provides a scalable upgrade path. This processor belongs to the Modicon series and serves as a powerful core for automation control. It supports 512 discrete I/O points and 24 analogue I/O inputs, making it suitable for applications requiring extensive data interaction.
Technical Specifications Breakdown
The Schneider TSXP571634 offers the following key specifications:
| Parameter |
Value |
| Discrete I/O Capacity |
512 I/O |
| Analogue I/O Capacity |
24 I/O |
| Application-Specific Channels |
8 |
| Memory (with PCMCIA card) |
224 kB program, 96 kB data |
| Memory (without PCMCIA card) |
96 kB program and data |
| Current Consumption |
1650 mA |
| Input Voltage |
5 VDC |
| Protection Class |
IP20 |
| Operating Altitude |
0 to 2000 m |
| Operating Temperature |
0 to 60 °C |
| Storage Temperature |
-25 to 70 °C |
The 512 discrete I/O capacity suits medium to large control systems, while the 24 analogue channels allow precise handling of sensor signals. The 8 application-specific channels enable targeted operations like high-speed counting or motion control. Memory resources ensure adequate storage for complex programs even without the optional PCMCIA card.
Industry Applications
In manufacturing lines requiring migration from legacy controllers, the TSXP571634 integrates seamlessly, offering enhanced memory and I/O density. For process control with mixed discrete and analogue signals, its channels enable precise regulation. The device’s compact size and IP20 rating make it ideal for clean industrial environments like packaging or assembly.
Maintenance & Reliability
The Schneider TSXP571634 features IP20 protection, suitable for environments where protection from solid objects is essential. Its operating temperature range of 0 to 60 °C ensures reliable performance in most factory floors. Regular inspection of the PCMCIA card slot and connections is recommended to maintain uptime. The robust design minimizes maintenance needs, contributing to long-term cost savings.
Selection Guide & Purchasing Advice
Before purchasing, verify your backplane compatibility with the Modicon Unity platform. Ensure your power supply can deliver 1650 mA at 5 VDC. For assistance with product fit or application questions, contact PLC Source PRO or visit ubest101 for reliable sourcing. This processor is a direct replacement for older Modicon models and a smart upgrade for expanding systems.
