Product Introduction
With a rated voltage of 24V DC and power consumption of only 15 watts, the Schneider TSXP47425 Modicon controller delivers precise operations in industrial environments. This industrial automation module from the Modicon series offers a robust design with an operating temperature range from -10°C to +60°C, making it suitable for demanding factory floors.
Technical Specifications Breakdown
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Product Line |
Modicon |
| Part Number |
TSXP47425 |
| Weight |
2.63 lbs (1.19 kg) |
| Rated Voltage |
24V DC |
| Rated Current |
1.2 A |
| Power Consumption |
15W |
| Operating Temperature Range |
-10°C to +60°C |
| Storage Temperature Range |
-25°C to +70°C |
| Degree of Protection |
IP20 |
| Communication Interface |
Modbus, Ethernet, CANopen, Profibus DP |
| Memory Capacity |
1MB program memory, 128KB data memory |
| Input Voltage Range |
20V to 30V DC |
| Program Scan Time |
1 ms per 1K of program memory |
| I/O Capacity |
256 digital I/O, 128 analog I/O |
| Number of Expansion Slots |
4 |
| Mounting Type |
DIN rail mounting |
| Real-Time Clock |
Integrated, battery-backed |
The TSXP47425's low power consumption of 15W contributes to reduced energy costs over long-term operation, a key benefit for facilities running multiple controllers.
Application Scenarios
In machine control applications, the TSXP47425's 256 digital I/O and 128 analog I/O provide ample points for sensors and actuators. Its support for Modbus, Ethernet, CANopen, and Profibus DP ensures seamless integration with existing networks. For process automation, the wide input voltage range (20V to 30V DC) and operating temperature range (-10°C to +60°C) make it reliable even in fluctuating conditions.
Another common use is as a replacement controller in legacy systems. The TSXP47425 offers enhanced memory and faster scan times compared to older Modicon modules, reducing program execution delays.
Compatibility & Integration
- Supports multiple industrial protocols: Modbus, Ethernet, CANopen, and Profibus DP.
- Four expansion slots allow adding I/O or communication modules.
- DIN rail mounting simplifies installation in control panels.
- Integrated battery-backed real-time clock ensures time-stamped data logging.
