Product Introduction
When upgrading your control system, the Schneider TSXH5724M micro PLC delivers enhanced performance and connectivity over older models. Part of the TSX Micro PLCs series, this compact module supports up to 1024 discrete I/O and 80 analog I/O, making it suitable for a wide range of industrial automation tasks. Its integrated Ethernet TCP/IP, USB, and RS485 ports simplify network integration, reducing wiring and installation costs.
Technical Specifications
The Schneider TSXH5724M offers the following key specifications:
- Discrete I/O Capacity: 1024 I/O
- Analog I/O Capacity: 80 I/O
- Number of Racks: 1 (6/8/12 slots)
- Application-Specific Channels: ≤ 24
- Process Control Channels: ≤ 10 (up to 30 simple loops)
- Integrated Connections: Ethernet TCP/IP RJ45, USB type A (12 Mbit/s), serial link RS485 (19.2 kbit/s)
- Memory: Internal RAM (with PCMCIA card: 768 kB program, 192 kB data; without: 192 kB program+data) + PCMCIA up to 16384 kB data storage
- Execution Time: 0.039–0.073 µs (Boolean, fixed-point, floating-point)
- Number of Instructions per ms: 11.4 Kinst/ms (65% Boolean + 35% fixed arithmetic), 15.75 Kinst/ms (100% Boolean)
- System Overhead: 1 ms master task
- Net Weight: 1.23 lb (0.56 kg)
- Marking: CE
Industry Applications
The TSXH5724M excels in applications such as material handling, packaging, and water treatment. For example, in a conveyor system, the 1024 discrete I/O capacity allows monitoring of numerous sensors and actuators, while the 80 analog channels handle variable-speed drives. The integrated Ethernet port enables seamless connection to SCADA systems, reducing downtime through remote diagnostics.
Compatibility & Integration
With integrated Ethernet TCP/IP (10BASE-T/100BASE-TX), USB type A (12 Mbit/s), and a serial RS485 link (19.2 kbit/s), the Schneider TSXH5724M easily connects to PLCs, HMIs, and field devices. It is designed for the Modicon Premium automation platform and works with Unity Pro software, simplifying programming and maintenance. The PCMCIA memory expansion supports large programs and data logs.
Selection Guide & Purchasing Advice
When selecting the TSXH5724M, verify your rack size (6, 8, or 12 slots) and ensure your power supply provides 5 VDC at 1880 mA. For a reliable source, consider UBEST Automation, which stocks genuine Schneider modules with fast shipping. Always confirm compatibility with your existing I/O modules and communication protocols before ordering.
