Overview of the Schneider TSXETY4103 Ethernet TCP/IP Module
The Schneider TSXETY4103 Ethernet TCP/IP module is designed to bring modern networking capabilities to the TSX Micro PLCs series. As a replacement for legacy serial communication, this module enables efficient data exchange and remote monitoring. Its standard format fits seamlessly into existing racks, making it an ideal upgrade for industrial automation systems.
TSXETY4103 Technical Specifications
| Parameter |
Value |
| Communication Interface |
RJ45 - 10BASE-T/100BASE-TX |
| Transmission Rate |
10/100 Mbit/s |
| Protocols |
Uni-Telway, Modbus TCP |
| Max. Connections |
64 |
| Current Consumption |
360 mA at 5 V DC |
| Weight |
1.00 lbs (0.45 kg) |
| Supply |
Via rack power supply |
Compatibility and Integration with PLC Systems
The TSXETY4103 integrates with TSX Micro PLCs using PL7 Pro or Unity Pro software. It supports web services like rack viewer and data editor, and offers transparent ready class B30 web features. Communication services include bandwidth management, FDR server, and Modbus TCP messaging, ensuring robust connectivity for control systems.
Common Issues and Troubleshooting for the TSXETY4103
The module features four diagnostic LEDs (COL, RUN, ERR, TX/TR) to quickly identify network status. Common issues include incorrect IP configuration or cable faults. Verify that the RJ45 connection uses twisted pair cable and that the module is properly seated in the rack. The CE marking confirms compliance with industrial standards.
Selection Guide and Purchasing Advice
When upgrading to the Schneider TSXETY4103, ensure your rack power supply can deliver 360 mA at 5 V DC. This module is compatible with TSX Micro PLCs and requires appropriate software. For reliable sourcing, contact UBEST Automation at ubest101 to verify stock and compatibility with your existing system.
