Product Introduction
When your automation system demands reliable control of multiple discrete outputs, the Schneider TSXDSY64T2K delivers robust performance. Part of the Modicon Premium automation platform, this discrete output module provides 64 solid-state protected outputs designed for 24 V DC positive systems. It integrates seamlessly into the Schneider Electric TSX Micro PLC range, offering comprehensive protection against short circuits, overloads, and reverse polarity. The TSXDSY64T2K ensures your machinery operates safely and efficiently, reducing unplanned downtime.
Technical Specifications Breakdown
The TSXDSY64T2K features 64 discrete outputs, each rated at 0.1 A maximum, with a total module current of up to 5 A. Its response time of 1.2 ms enables fast switching for demanding applications. Leakage current remains below 0.1 mA at 30 V, minimizing power waste. The module supports paralleling of up to three outputs for higher current needs, and handles tungsten loads up to 1.2 W. Residual voltage is kept under 1.5 V, ensuring clean signal transitions. Protection includes output overvoltage protection via a transil diode, reverse polarity protection via a reverse-mounted diode, and automatic trip for both short-circuit and overload conditions.
Industry Applications
In manufacturing lines requiring high-density output control, the TSXDSY64T2K excels. For example, in a packaging facility, it can manage 64 solenoid valves or indicator lights simultaneously, with each channel protected against overload. Its solid-state design eliminates mechanical wear, making it ideal for high-cycle applications like conveyor sorting systems. The module's automatic trip protection prevents damage from wiring faults, reducing maintenance costs and improving uptime.
Installation & Setup Guidance
Mount the TSXDSY64T2K in a standard Modicon Premium rack using the provided HE-10 connectors. Ensure the 24 V DC positive supply is within the 19...30 V range per EN/IEC 61131-2. Connect outputs with load impedance above 220 Ω at state 1 to guarantee proper operation. Verify the module format is standard and fits your enclosure. For paralleling outputs, limit to three maximum to stay within current ratings. Always power down before making connections.
Maintenance & Reliability
The TSXDSY64T2K requires minimal maintenance due to its solid-state construction. Inspect connections periodically for tightness and check for signs of moisture or contamination. Operate within the ambient temperature range of 32…140 °F (0…60 °C) and relative humidity of 10…95 % without condensation. The IP20 protection degree suits clean indoor environments. Automatic trip protection reduces the need for fuse replacements, lowering total cost of ownership.
Compatibility & Integration
The TSXDSY64T2K is designed for the Modicon Premium automation platform and TSX Micro PLC systems. It uses four HE-10 connectors for electrical connection and draws 155 mA at 5 V DC from the backplane. The module is CE marked and complies with standards including UL 508, CSA C22.2 No 213, and IEC 61131-2. It carries certifications from RINA, DNV, BV, ABS, GL, RMRS, and LR, making it suitable for marine and industrial applications.
Buying Guide & Purchasing Advice
Before ordering the TSXDSY64T2K, verify your system's compatibility with the Modicon Premium platform and confirm the 24 V DC positive supply voltage. Check that your application requires 64 discrete outputs and that the 0.1 A per channel rating meets your load requirements. BluePLC Industrial offers this module with fast shipping and expert support. Contact us to confirm current lifecycle status and availability before placing your order.
