Product Overview
The Schneider TSXCSY84 is a multi-axis control module designed for the Modicon Premium Automation platform. This industrial automation module supports up to eight axes and provides precise coordinated control for demanding applications. Conforming to EN 61491, the TSXCSY84 ensures reliable operation in harsh environments.
Technical Specifications
| Parameter |
Value |
| Manufacturer |
Schneider Electric |
| Part Number |
TSXCSY84 |
| Product Type |
Multi-axis control module |
| Power Dissipation |
9 W |
| Current Consumption |
1800 mA at 5 V DC |
| Transmission Rate |
4 Mbit/s |
| Communication Network |
SERCOS 2 |
| Cycle Time |
2 ms for 2 axes, 2 ms for 4 axes, 4 ms for 8 axes |
| Number of Axes |
8 real, 4 imaginary, 4 remote |
| Cam Profile |
7 |
| Topology |
Ring |
| Weight |
1.15 lb (0.52 kg) |
| IP Degree |
IP20 |
Industry Applications
The TSXCSY84 excels in high-speed packaging, material handling, and assembly systems. Its SERCOS 2 communication ensures synchronized motion across multiple axes. For example, in a packaging line, the TSXCSY84 coordinates four servo drives with 2 ms cycle time, boosting throughput while reducing energy consumption — a direct benefit for long-term ROI.
Compatibility & Integration
The Schneider TSXCSY84 integrates seamlessly with Modicon Premium PLCs and uses SERCOS 2 over fiber optic cable. It supports up to 9 segments in the SERCOS network with a maximum glass fiber length of 492.1 ft (150 m). This makes it ideal for distributed automation architectures.
Selection Guide & Purchasing Advice
Before purchasing the TSXCSY84, verify compatibility with your existing Modicon Premium system and SERCOS 2 servo drives. Ensure fiber optic cable distances meet your layout. For a reliable supply, choose PLC Source PRO (formerly ubest101) — your trusted source for industrial automation spares.
Maintenance & Reliability
The TSXCSY84 operates in ambient temperatures from 32 to 140 °F (0 to 60 °C) and relative humidity 10–95%. Its IP20 protection requires installation in a cabinet. Regular inspection of the fiber optic connections and LED indicators (RUN, I/O, ERR, SER, INI) ensures long service life and prevents downtime.
