Product Introduction
In demanding industrial environments, connection failures due to humidity or temperature fluctuations can halt production. The Schneider TSXCDP203 connecting cable is engineered to maintain reliable communication within Modicon systems. Part of the Modicon Premium family, this 2-meter cable features HE10 20-way connectors on both module and PLC sides, ensuring secure signal transmission even in harsh conditions.
Technical Specifications
Below are the key parameters validated for the TSXCDP203:
-
Manufacturer: Schneider Electric
-
Product Type: Connecting Cable
-
Product Line: Modicon
-
Part Number: TSXCDP203
-
Cable Length: 2 meters (6.6 ft)
-
Connector Type: HE10, 20-way (module side and PLC side)
-
Wire Section: 0.324 mm² (AWG 22)
-
Maximum Operating Humidity: 80% RH without condensation
-
Maximum Storage Humidity: 80% RH without condensation
-
Temperature Rating: -10°C to 60°C
-
Voltage Rating: 250V AC
-
Current Rating: Max 5A
-
Shielding Type: Unshielded
-
Packaging Type: Individual package
-
Net Weight: 0.28 kg (0.62 lb)
These specifications make the Schneider TSXCDP203 a robust choice for industrial control systems where environmental extremes are common.
Industry Applications
The TSXCDP203 is specifically designed for use with Modicon Premium and other Modicon series PLCs. Common applications include:
- Connecting input/output sub-bases such as ABE7H16R20 in manufacturing lines.
- Interfacing with expansion modules like TSXCFY11, TSXCAY, or TSXCCY1128.
- Providing flexible cabling between PLC racks in distributed control system (DCS) installations.
Thanks to its 80% RH humidity rating and wide temperature range, this cable reduces failure modes related to condensation and thermal stress, ensuring long-term reliability in automotive, food processing, and chemical plants.
Installation & Setup Guidance
Installing the TSXCDP203 is straightforward. Align the HE10 20-way connector with the corresponding port on the module or PLC side. Ensure the locking clips snap securely. Because the cable is unshielded, avoid routing it parallel to high-voltage power lines to prevent electromagnetic interference. The 2-meter length offers flexibility for cabinet layouts without excessive slack.
Compatibility & Integration
The Schneider TSXCDP203 integrates seamlessly with the Modicon Premium series and is compatible with sub-bases, adapters, and terminal blocks listed in the product documentation. Verified compatible devices include TSXCFY11, TSXCAY, TSXCFY21, TSXCTY2C, TSXCTY4A, TSXCTY2A, and TSXCCY1128. Always cross-check your PLC model and sub-base part number to ensure proper connection.
Maintenance & Reliability
To maximize the TSXCDP203 lifespan, inspect connectors periodically for dust or corrosion. The maximum storage humidity of 80% RH means the cable can be stored in most non-condensing environments. Avoid exceeding the -10°C to 60°C temperature range during operation. For preventive maintenance, replace the cable if you notice intermittent connectivity issues—especially in high-humidity areas where condensation might develop on connectors.
Choose reliable suppliers like PLC Source PRO for genuine Schneider TSXCDP203 cables. Verify the part number on the packaging to avoid counterfeits.
