Product Overview
When precise motion control is critical, the Schneider Electric TSXCAY33 delivers reliable servo motor management. This motion control module, part of the TSX Micro PLCs series, is engineered for accurate positioning and flexible operation. With support for trapezoidal or parabolic speed profiles and acquisition speeds up to 270,000 points per minute, the TSXCAY33 minimizes cycle times and reduces overall system downtime, offering long-term cost benefits.
The TSXCAY33 from Schneider Electric handles complex motion tasks with a servo loop type proportional to overshoot compensation and gain switching. This ensures responsive control and stable performance in demanding industrial environments.
Technical Specifications
The following table highlights key parameters of the Schneider TSXCAY33:
| Parameter |
Value |
| Product Type |
Motion Control Modules |
| Product Line |
TSX Micro PLCs |
| Application |
For Servo Motors |
| Acquisition Speed |
≤ 270,000 points/min, ≥ 54,000 points/min |
| Resolution |
≤ 1000 position units per point, ≥ 0.5 position units per point |
| Power Dissipation |
10 – 17 W |
| Clock Frequency |
200 kHz SSI absolute encoder; incremental encoder x1: 500 kHz; x4: 1000 kHz counting, 250 kHz input |
| Input Compatibility |
Absolute encoder SSI 12–25 bits, incremental encoder 10–30 V totem pole, 5 V DC RS422, 2‑wire/3‑wire sensor (24 DC), absolute encoder parallel output ABE7CPA11 |
| Input Voltage |
24 V 8 mA auxiliary input, 24 V 8 mA servo drive control input, 5 V 18 mA counter input |
| Operating Modes |
OFF, FOLLOWER, Manual, Direct drive mode, Automatic |
| Type of Axis |
2/3 axis linear interpolation |
| Weight |
1.00 lbs (0.45 kg) |
Application Scenarios
The Schneider TSXCAY33 excels in multi‑axis servo control applications such as packaging machinery, pick‑and‑place systems, and CNC routers. Its high acquisition speed and resolution allow for precise position feedback, while the flexible operating modes enable seamless transitions between manual setup and automatic production.
For example, in a packaging line, the TSXCAY33 can coordinate two or three axes for simultaneous linear interpolation, reducing cycle time by up to 20% compared to older step‑motor solutions. This directly translates to higher throughput and lower cost per unit.
Installation & Setup Guidance
Mount the Schneider TSXCAY33 in a standard TSX Micro PLC rack. Ensure proper grounding and use shielded cables for encoder connections to minimize noise. Wire auxiliary inputs and servo drive control inputs according to the provided pinout. The module requires a 24 V DC supply for auxiliary and servo inputs, and a 5 V DC supply for counter inputs. Verify that the voltage levels stay within the limits: 19–30 V for auxiliary and servo inputs, and ≤ 5.5 V for counter inputs. After installation, perform a consistency check of commands and encoder coupling before enabling the drive.
Compatibility & Integration
The Schneider TSXCAY33 integrates seamlessly with TSX Micro PLCs and Modicon Premium automation platforms. It supports absolute encoders with SSI output (12–25 bits) and incremental encoders with totem pole or RS422 outputs. For input flexibility, the module accepts 2‑wire/3‑wire sensors and absolute encoders with ABE7CPA11 parallel output. The module provides reflex outputs and analogue outputs for direct servo drive control, making it a versatile choice for new installations or upgrades.
Selection Guide & Purchasing Advice
When selecting the Schneider TSXCAY33, verify that your system’s power supply meets the current consumption requirements: 22–40 mA at 24 V DC (with absolute encoder), 1500 mA at 5 V DC, and 30 mA at 24 V DC. Ensure that the encoder type and resolution match your application needs. For reliable sourcing, purchase from PLC Source PRO (formerly ubest101) to guarantee genuine parts and expert support.
