Product Overview
The Schneider TSXCANKCDF90T CANopen connector with line terminator is a dedicated accessory for CANopen bus systems. Designed for reliable signal termination and easy integration, this female connector features a SUB-D9 elbowed interface and robust IP20 protection. The TSXCANKCDF90T ensures proper bus impedance matching, reducing reflections and communication errors in industrial automation networks.
Technical Specifications
Key parameters of the Schneider TSXCANKCDF90T are listed below. For detailed specifications not available here, contact PLC Source PRO directly.
| Parameter |
Value |
| Bus Type |
CANopen |
| IP Degree of Protection |
IP20 |
| Electrical Connection |
1 female connector SUB-D 9 elbowed |
| Weight |
0.046 kg (0.1 lb) |
| Warranty Period |
18 months |
Industry Applications
The TSXCANKCDF90T is ideal for CANopen fieldbus networks in factory automation, packaging machinery, material handling, and process control. Use it to upgrade older systems or replace worn connectors to maintain stable communication. In robotic cells, it prevents bus faults by providing correct line termination.
Installation & Setup Guidance
Mount the Schneider TSXCANKCDF90T connector at the end of the CANopen bus segment. Ensure the device is powered off during installation. Connect the SUB-D9 female plug to the mating male connector on the device or cable. The elbowed design helps in tight spaces and cable routing. No tools are required beyond standard screwdriver for cable clamping.
Compatibility & Integration
This connector is fully compatible with Schneider CANopen devices and standard CANopen networks. It works with PLC controllers, drives, I/O modules, and other fieldbus nodes. The built-in terminator eliminates the need for external termination resistors. For best performance, use the TSXCANKCDF90T at both bus ends in a standard CANopen topology.
Selection Guide & Purchasing Advice
Before purchasing the TSXCANKCDF90T, verify your system requires male or female termination and the correct connector angle. This unit is a female connector with a right-angle (elbowed) exit. For reliable supply, order from PLC Source PRO (formerly ubest101). One unit per bus segment is usually sufficient, but check your network design.
