Product Introduction
The Schneider TSXCANCBDD5 is a high-quality CANopen cordset designed for industrial automation networks. Part of the CANopen range, this molded cable assembly provides a standard IP20-rated connection with female SUB-D9 connectors. With a length of 16.4 ft (5 m), it offers flexibility in wiring cabinets and field devices.
Technical Specifications
| Specification |
Value |
| Product Type |
CANopen cordset |
| Bus Type |
CANopen |
| Connector Type |
2 female SUB-D9 |
| Cable Length |
16.4 ft (5 m) |
| IP Rating |
IP20 |
| Certifications |
UL, CE |
| Weight |
0.9 lb (0.4 kg) |
These specifications ensure the Schneider TSXCANCBDD5 meets rigorous industrial standards for signal integrity and mechanical durability.
Compatibility & Integration
The Schneider TSXCANCBDD5 is intended for use on CANopen bus networks. It connects seamlessly with CANopen master/slave devices, PLCs, and distributed I/O modules. The female SUB-D9 connectors provide a secure locking mechanism to prevent accidental disconnection. For optimal performance, verify that your system operates at the standard CANopen baud rates and uses the correct pinout (pins 2 and 7 for CAN_L and CAN_H). This cordset is a reliable drop cable for connecting nodes in a daisy-chain or star topology.
Installation & Setup Guidance
Install the Schneider TSXCANCBDD5 by first ensuring power is off. Connect the female SUB-D9 connectors to the male ports on your devices. Tighten the screws by hand to avoid over-torquing. Route the cable away from high-voltage lines and sharp edges. Because the cordset is rated IP20, use it only in clean, dry indoor environments (e.g., control cabinets). Verify continuity with a multimeter after installation. The 5-meter length gives ample reach for most cabinet layouts.
Maintenance & Reliability
The Schneider TSXCANCBDD5 is built for long service life with molded connectors that resist strain and vibration. Inspect the cable periodically for cuts or kinks; replace if damage is visible. The IP20 rating means no sealing against dust ingress in heavy industrial areas, so mount in enclosures where cleanliness is maintained. UL and CE certifications confirm compliance with safety and performance norms, reducing the risk of downtime due to connectivity failures. For maximum ROI, stock spare cordsets to swap quickly during maintenance windows.
Selection Guide & Purchasing Advice
Before purchasing the Schneider TSXCANCBDD5, confirm that your application requires a male-to-female CANopen cable with SUB-D9 connectors. If you need a different length or connector style, consider other models in the CANopen cordset family. For bulk orders or technical support, contact PLC Source PRO (formerly ubest101) for fast assistance. Always verify your existing system's pinout—this cordset uses the standard CANopen pin assignment. Ensure your controller supports the CANopen protocol.
