Reliable Connectivity for CANopen Networks
When CANopen network connectivity fails due to poor cable quality or loose connections, the Schneider TSXCANCBDD3 provides a robust solution. This CANopen cordset is designed to ensure stable and secure communication in industrial automation environments. With molded female SUB-D9 connectors and UL certification, it reduces the risk of signal loss and physical damage.
Technical Specifications
| Parameter |
Value |
| Bus Type |
CANopen |
| Cable Length |
3 m |
| Electrical Connection |
2 female connectors SUB-D 9 pin(s) |
| Product Weight |
0.268 kg |
| IP Degree of Protection |
IP20 |
| Product Certifications |
UL, CE |
Industry Applications
The Schneider TSXCANCBDD3 is ideal for connecting devices on a CANopen bus, such as PLCs, drives, sensors, and actuators. Common applications include automated assembly lines, packaging machinery, and material handling systems. Its robust molded design prevents connector strain and signal degradation, even in demanding plant-floor conditions.
Installation & Setup Guidance
To install the Schneider TSXCANCBDD3, simply plug the female SUB-D9 connectors into the corresponding male ports on the CANopen devices. Ensure the locking screws are hand-tightened to avoid loosening from vibration. Route the cable with a minimum bend radius of 5 cm to protect the internal conductors. Avoid placing the cable near high-voltage lines or heat sources.
Maintenance & Reliability
Regularly inspect the Schneider TSXCANCBDD3 for cuts, kinks, or connector damage. Clean the connector pins with a dry cloth if contaminants are present. Because the cordset is rated IP20, it is suitable for clean, dry environments. Periodic checks every 6 months help prevent unexpected downtime and extend service life.
Selection Guide & Purchasing Advice
Before purchasing, verify that your devices have SUB-D9 male ports and that a 3-meter cable length fits your cabinet layout. The Schneider TSXCANCBDD3 is a standard CANopen cable; for longer distances, consider using repeaters or signal boosters. For reliable sourcing and competitive pricing, contact ubest101 directly.
