Product Introduction – Reliable CANopen Communication
When intermittent communication errors threaten your CANopen network, the Schneider TSXCANCBDD1 cordset provides a robust, factory-tested solution. This molded cable assembly ensures consistent signal integrity and mechanical durability, reducing downtime in critical industrial automation applications.
Technical Specifications
The Schneider TSXCANCBDD1 offers the following key parameters:
| Specification |
Value |
| Cable Length |
3.3 ft (1 m) |
| Connector Type |
2 female connectors SUB-D 9 |
| IP Degree of Protection |
IP20 |
| Product Weight |
0.289 lb (0.131 kg) |
| Certifications |
UL, CE |
| Bus Type |
CANopen |
Real-World Applications
Ideal for connecting CANopen fieldbus devices, the Schneider TSXCANCBDD1 excels in environments where reliable point-to-point links are essential. Common use cases include:
- Communication between a PLC and remote I/O modules on a CANopen network.
- Connection of variable frequency drives to a supervisory control system.
- Interfacing sensors or actuators in a distributed automation architecture.
Installation & Setup Guidance
Installation of the Schneider TSXCANCBDD1 is straightforward. Its molded female SUB-D9 connectors require no special tools; simply insert and tighten the screws. To maintain signal quality, avoid sharp bends and keep the cable away from high‑voltage power lines. The IP20 rating limits use to dry indoor locations.
Compatibility & Integration
This cordset is designed for any CANopen bus, regardless of device brand. It works seamlessly with Schneider Electric controllers, drives, and sensors, as well as third‑party CANopen equipment. The 1‑meter length is ideal for short‑distance cabinet wiring.
Selection Guide & Purchasing Advice
Before purchasing the Schneider TSXCANCBDD1, verify that your application requires a 1‑meter cable, female SUB-D9 connectors, and an IP20 rating. For longer runs, consider multiple cordsets or a repeater. For genuine parts and fast shipping, order from ubest101 (PLC Source PRO).
