1. What is the primary function of the TSXCANCBDD03 module?
The TSXCANCBDD03 is a CANopen bus distribution block designed to terminate and connect multiple devices on a CANopen network, ensuring proper signal integrity.
2. What type of connectors does the TSXCANCBDD03 use?
The TSXCANCBDD03 features two 9-pin SUB-D connectors (one male, one female) for daisy-chaining CANopen devices, as per standard CANopen physical layer specifications.
3. Does the TSXCANCBDD03 include a termination resistor?
Yes, the TSXCANCBDD03 typically incorporates a 120-ohm termination resistor that can be enabled via a switch to match the CAN bus characteristic impedance.
4. What is the voltage rating for the TSXCANCBDD03?
The TSXCANCBDD03 is rated for CANopen bus voltages up to 5 VDC, conforming to the CAN physical layer standard for signal levels.
5. In which Schneider product families can the TSXCANCBDD03 be used?
The TSXCANCBDD03 is designed for use with Schneider Modicon Premium and Quantum automation platforms as a CANopen bus termination module.
