Product Overview: Schneider TSXCANCADD5 CANopen Cordset
The Schneider TSXCANCADD5 is a high-quality CANopen cordset designed for industrial automation networks. This molded cable features two female SUB-D9 connectors and a standard 5-meter length, making it ideal for connecting CANopen devices in PLC, DCS, and motion control systems. With an IP20 rating, it is suitable for cabinet installations where protection from solid objects is required. The TSXCANCADD5 ensures reliable data transmission and is CE marked for compliance.
Key Technical Specifications
| Parameter |
Value |
| Product Type |
CANopen cordset |
| Electrical Connection |
2 female connectors SUB-D 9 |
| Cable Length |
16.4 ft (5 m) |
| IP Degree of Protection |
IP20 |
| Product Weight |
0.97 lb (US) (0.44 kg) |
| Marking |
CE |
| Bus Type |
CANopen |
The Schneider TSXCANCADD5 is a connecting cable specifically designed for CANopen bus networks. Its molded construction ensures durability and strain relief at the connector points, reducing the risk of signal loss or intermittent faults. The 5-meter length offers flexibility for connecting devices within a control cabinet or short distances between equipment.
Real-World Applications
In typical industrial automation settings, the Schneider TSXCANCADD5 is used to connect CANopen master controllers to remote I/O modules, drives, or sensors. For example, in a packaging line, this cordset can link a Schneider PLC to a series of actuator modules, ensuring synchronized operation. In a material handling system, it connects distributed I/O blocks to the central control system, reducing wiring complexity. The IP20 rating makes it ideal for clean environments like control cabinets, while the robust connectors withstand repeated plug/unplug cycles during maintenance.
Installation and Setup Guidance
Installing the Schneider TSXCANCADD5 is straightforward. Simply connect one female SUB-D9 connector to the CANopen master device and the other to the target device. Ensure the connectors are fully seated and the locking screws are tightened to prevent accidental disconnection. Avoid sharp bends in the cable, as the 5-meter length should be routed with a minimum bend radius of approximately 10 cm to maintain signal integrity. For best practice, use cable ties to secure the cordset along the cabinet path, avoiding contact with heat sources or moving parts.
Integration and Compatibility
This cordset is fully compatible with any device utilizing the CANopen communication protocol. It works seamlessly with Schneider Electric PLCs, drives, and remote I/O modules, as well as third-party CANopen-compliant equipment. The standard SUB-D9 interface ensures broad compatibility across industrial automation brands. When integrating the Schneider TSXCANCADD5, verify that both ends of the connection support the same CANopen baud rate and node addressing. No special tools are required for installation.
Selection Guide and Purchasing Advice
When selecting a CANopen cordset, ensure the cable length meets your physical layout requirements. The Schneider TSXCANCADD5 at 5 meters is a versatile choice for most cabinet distances. If you need longer runs, consider using a repeater. Also verify that your devices use female SUB-D9 connectors; the TSXCANCADD5 is equipped with female connectors on both ends. For reliable supply and competitive pricing, purchasing from ubest101 ensures genuine Schneider products with fast shipping. Always check your network topology to avoid exceeding maximum cable length limits for CANopen (typically 250 m at lower baud rates).
