Product Overview
The Schneider TSXASY800 is an analog output module from the TSX Micro PLC series. It provides eight output channels capable of delivering voltage (0–10 V) or current (0–20 mA) signals. Designed for demanding process control applications, this module ensures high accuracy and reliable performance in space-constrained installations.
Technical Specifications
| Parameter |
Value |
| Number of Channels |
8 analog output |
| Output Type |
Voltage or current |
| Voltage Output Range |
0 to 10 V |
| Current Output Range |
0 to 20 mA |
| Resolution |
12-bit |
| Accuracy |
±0.1% of full scale |
| Minimum Load Impedance (current) |
500 ohms |
| Power Supply |
24 V DC |
| Power Consumption |
5 W |
| Isolation (channel to ground) |
500 V |
| Response Time |
1 ms per channel |
Industry Applications
The TSXASY800 excels in applications requiring precise analog output control, such as variable frequency drives, valve actuators, and temperature controllers. Its 12-bit resolution and fast 1 ms response ensure accurate and timely signal delivery, reducing waste and improving process efficiency. For example, in a chemical dosing system, the module maintains tight control over flow rates, minimizing downtime and material costs.
Maintenance and Reliability
With an operating temperature range of 0 to 60°C and humidity tolerance of 5 to 95% non-condensing, the TSXASY800 is built for harsh industrial environments. Its short-circuit and overload protection reduce the risk of failure, leading to longer service life and lower total cost of ownership. Routine inspection of connections and load impedance ensures sustained accuracy.
Selection Guide and Purchasing Advice
When selecting the Schneider TSXASY800, verify compatibility with your TSX Micro PLC base. Ensure your 24 V DC power supply meets the module's 5 W consumption and 300 mA current draw. For best performance, use shielded cables for analog signals. UBEST Automation (ubest101) offers this module with fast shipping and expert support, making it a reliable choice for your automation needs.
