Product Introduction
When industrial automation demands a compact yet powerful controller, the Schneider TSX3710101 delivers reliable performance. This micro PLC from Schneider Electric is part of the TSX Micro PLCs series, engineered for versatile automation solutions. With a voltage range of 100-240 V AC and input current from 2 mA to 60 A, it adapts to various project requirements, offering long-term cost benefits through reduced downtime and energy efficiency.
Technical Specifications
The Schneider TSX3710101 comes packed with essential features for precise control. Below are its key parameters derived from the product datasheet:
| Parameter |
Value |
| Voltage Rating |
100-240 V AC |
| Input Current |
2 mA - 60 A |
| Frequency |
50/60 Hz |
| Slots |
2 |
| Output Capacity |
Maximum 0.5 A |
| Analog Inputs |
8 slots (0-10 V) |
| Analog Outputs |
1 slot (0-10 V) |
| Communication Interfaces |
1 serial link Uni-Telway 19.2 kbit/s, 1 Modbus RTU 19.2 kbit/s |
| Memory |
Flash 15 Kwords, RAM 20 Kwords (expandable to 128 Kwords via PCMCIA) |
| Execution Time |
0.13 µs (Boolean) to 4.5 µs (REAL arithmetic) |
| Temperature Range |
32-140 °F (0-60 °C) |
| Humidity Range |
10% to 95% (non-condensing) |
| Dimensions |
13.44 x 5.94 x 5.98 in |
| Weight |
1.00 lbs (0.45 kg) |
These specifications ensure the Schneider TSX3710101 handles diverse automation tasks with high precision. For example, its fast execution time (0.13 µs for Boolean) reduces cycle times, contributing to overall system throughput.
Industry Applications
The Schneider TSX3710101 excels in applications such as packaging lines, material handling, and building automation. In a packaging line, its eight analog inputs can monitor sensors for position and pressure, while the single analog output controls a variable-speed drive. The Modbus RTU interface integrates seamlessly with SCADA systems, enabling remote monitoring and diagnostics. This flexibility reduces the need for multiple controllers, lowering total cost of ownership.
Compatibility & Integration
This micro PLC communicates via Uni-Telway and Modbus RTU at 19.2 kbit/s, making it compatible with legacy and modern Schneider systems. The 2 expansion slots allow for additional I/O modules. Its memory can be upgraded to 128 Kwords using a standard PCMCIA card, supporting complex programs. For integration, the Schneider TSX3710101 works with PL7 software and can be networked with other TSX Micro devices.
Selection Guide & Purchasing Advice
Before purchasing the Schneider TSX3710101, confirm your system voltage, required I/O count, and communication needs. Ensure you have the proper cabling for the serial link and Modbus. For memory expansion, order a compatible PCMCIA card separately. As a reliable supplier, ubest101 offers this PLC with fast shipping and expert support. Verify that your application does not exceed the 0.5 A output capacity per channel.
