Product Introduction
When industrial control systems demand reliable discrete I/O handling, the Schneider TSX1722028 PLC module from the Modicon series delivers robust digital control. Operating at 120/240 VAC with a current rating of 0.5/0.25 AMP, this versatile module is designed for straightforward automation tasks. The TSX1722028 features 10 digital inputs and 10 relay outputs, making it an excellent choice for standalone control applications.
Technical Specifications Breakdown
The Schneider TSX1722028 offers a tailored set of specifications for discrete control:
-
Input Voltage: 120/240 VAC – supports dual voltage ranges for global compatibility.
-
Current Rating (Input): 0.5/0.25 AMP – ensures low power consumption while maintaining reliable switching.
-
I/O Configuration: 10 inputs / 10 outputs – provides balanced signal handling for small to medium systems.
-
Output Type: Digital (Discrete) via relays – offers galvanic isolation and high switching capacity.
-
Temperature Range: -10°C to +60°C – ensures operation in harsh environments.
-
Signal Voltage: 24V DC for I/O – standard for industrial sensors and actuators.
The TSX1722028 uses relay outputs, which are ideal for applications requiring simple on/off control with high electrical endurance. The panel mount design simplifies integration into existing enclosures.
Industry Applications
The Schneider TSX1722028 fits into diverse industrial settings where discrete control is essential:
-
Conveyor Systems: Use the 10 digital inputs to monitor limit switches and proximity sensors, while the 10 relay outputs drive motor contactors.
-
Packaging Machinery: Control solenoid valves and indicator lights with reliable relay switching.
-
Material Handling: Implement simple logic sequences for sorting or diverting products.
Its wide temperature tolerance ensures stable performance in unheated facilities or outdoor cabinets.
Installation & Setup Guidance
Mount the TSX1722028 securely on a panel using the provided mounting holes. Connect AC power to the appropriate terminals (120V or 240V line) and neutral. Wire input signals (24V DC) from sensors to the input terminals, observing polarity where required. For outputs, connect relay contacts to loads using appropriate wire gauge for the current. Ensure the unit is powered off during wiring to prevent damage. No communication interface simplifies integration—just power and I/O wiring.
Maintenance & Reliability
Inspect the Schneider TSX1722028 periodically for dust accumulation and loose connections. Relay contacts may degrade after many cycles; monitor switching frequency and plan preventive replacement if needed. The wide temperature range reduces thermal stress, contributing to long service life. Keep the enclosure clean and ensure ventilation to maintain -10°C to +60°C operating limits.
Selection Guide & Purchasing Advice
Before purchasing the TSX1722028, verify your system's voltage compatibility (120/240 VAC) and ensure the I/O count (10 inputs, 10 outputs) meets your application requirements. The module is standalone with no built-in communication port; if network connectivity is needed, consider adding a separate gateway. For reliable sourcing, PLC Source PRO (available at ubest101) stocks genuine Schneider parts. Contact our team for assistance with matching this module to your control system.
