Product Introduction
In material handling and packaging environments, the Schneider TSX07211622 delivers consistent, efficient control. This programmable logic controller from the TSX Micro PLC series operates on a nominal 24 VDC power supply and supports dual-rated output voltage for both AC and DC applications. Its compact brick-style housing simplifies DIN rail installation, reducing setup time and total cost of ownership.
Technical Specifications
The Schneider TSX07211622 features robust electrical parameters that ensure reliable operation under demanding conditions. Below are the key specifications:
| Parameter |
Value |
| Power Supply Voltage |
24 VDC (nominal) |
| Input Current per Channel |
13 mA @ 24 VDC (sinking/sourcing) |
| Output Current Capacity |
2 A per channel (resistive/inductive) |
| Output Voltage Range |
240 VAC / 30 VDC (dual-rated) |
| Output Type |
Relay-based switching (electromechanical) |
| Mounting Configuration |
Compact brick-style, fixed DIN rail |
| Input Voltage Tolerance |
24 VDC ±10% |
| Output Contact Configuration |
Form-C (SPDT) relay contacts |
The dual-rated output voltage of the Schneider TSX07211622 eliminates the need for separate AC and DC modules, reducing inventory costs and simplifying spares management. Its relay output provides reliable switching for resistive and inductive loads, contributing to lower downtime in continuous processes.
Industry Applications
The Schneider TSX07211622 is designed for material handling, packaging, and textile machinery. In packaging lines, it controls conveyors and actuators with both AC and DC loads, improving operational flexibility. For textile machinery, the dual-voltage capability allows direct control of European and North American equipment without interface modules. This versatility reduces spare part stock and training requirements, delivering measurable ROI.
Installation & Setup
Mount the Schneider TSX07211622 on a standard DIN rail using the integrated clips. Ensure the power supply is 24 VDC ±10% and connect inputs per the sinking or sourcing configuration. Wire outputs to Form-C relay terminals, observing the load ratings: up to 2 A per channel for resistive loads. The compact brick-style housing fits tight panels and simplifies wiring access. Verify that the input voltage tolerance remains within the specified range to avoid erratic operation.
Selection Guide & Purchasing Advice
Before purchasing, confirm that your system requires 24 VDC power and that the output voltage range (240 VAC / 30 VDC) matches your driven loads. The Schneider TSX07211622 supports both sinking and sourcing inputs, offering flexibility in field wiring. For guaranteed authentic parts, order from PLC Source PRO (ubest101.myshopify.com). Our inventory includes genuine Schneider modules ready for immediate shipment, ensuring minimal downtime for your operations.
